Research and Development of FPGA Solar MPPT Algorithm

Abstract:

In order to improve the development using FPGA solar panels generating speed, through the study on the solar panel maximum power output perturbation method (MPPT) how to develop and how to improve the development efficiency were studied. This algorithm through MATLAB Simulink simulation is confirmed, then use generator to simulate the algorithm, and the algorithm is downloaded into the FPGA, the hardware co_simulation, design of MPPT circuit will be in accordance with the circuit parameters of the modified. Through the hardware circuit operating results, it is proved that the algorithm design of circuit is correct and meet the design requirements, also demonstrate the utility of using generator hardware co_simulation method for the development of FPGA. The development method can improve the design speed, shorten the reliability of control, the development cycle and reduce development costs, achieve a fully compatible and replace physical circuit.

• Periodical: Applied Mechanics and Materials (Volume 740)
• Pages: 375-378
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.740.375
• Online since: March 2015
• Authors: Qing Liang Qin*
• Keywords: FPGA, Hardware Co_Simulation, MATLAB, MPPT, Perturbation Method
