On the Research of Identification Methods for Supercapacitor Model Parameters

Abstract:

The accuracy of model becomes increasingly demanding in the simulation system with the development of supercapacitor. The traditional methods of parameters identification in supercapacitor modeling are very complicated. This paper presents an easy and new method by the Simulink tool. The experimental data for the identification of the model parameters was obtained through the constant charge-discharge experiments. Then the variable capacitor of the supercapacitor equivalent circuit model was modeled in Simscape Language, so parameters directly got with Parameter estimation in Sumulink. Simulation results were presented and compared experimental data. And the result showed that the new method was not only speeded the identification of parameters, but also improved the modeling precision up to 98%.

• Periodical: Applied Mechanics and Materials (Volume 740)
• Pages: 499-502
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.740.499
• Online since: March 2015
• Authors: Qi Li*, Wen Bin Zhang, Ping Li, Shi Su, Yu Ting Yan, Yang Yang
• Keywords: Equivalent Circuit Model, Identification, Parameters, Simscape Language, Supercapacitor

References

[1] Diab, Y., et al., Self-discharge characterization and modeling of electrochemical capacitor used for power electronics applications. Power Electronics, IEEE Transactions on, 2009. 24(2): pp.510-517.

DOI: 10.1109/tpel.2008.2007116

[2] Moayedi, S., F. Cingoz, and A. Davoudi, Accelerated Simulation of High-fidelity Models of Supercapacitors Using Waveform Relaxation Techniques. (2013).

DOI: 10.1109/tpel.2013.2250522

[3] Shi, L. and M. Crow. Comparison of ultracapacitor electric circuit models. in Power and Energy Society General Meeting-Conversion and Delivery of Electrical Energy in the 21st Century, 2008 IEEE. 2008. IEEE.

DOI: 10.1109/pes.2008.4596576

[4] Bonert, R. and L. Zubieta. Measurement techniques for the evaluation of double-layer power capacitors. in Industry Applications Conference, 1997. Thirty-Second IAS Annual Meeting, IAS '97., Conference Record of the 1997 IEEE. (1997).

DOI: 10.1109/ias.1997.628998

[5] IEC 62391-1 Fixed electric double-layer capacitors for use in electronic equipment. (2006).

[6] Huria, T., et al. High fidelity electrical model with thermal dependence for characterization and simulation of high power lithium battery cells. in Electric Vehicle Conference (IEVC), 2012 IEEE International. 2012. IEEE.

DOI: 10.1109/ievc.2012.6183271
