Kinematic Analysis of Swash Plate Axial Piston Pump Based on Adams Simulation

Abstract:

The swash plate axial piston pump is a main part in liquid press system.It is a positive displacement pump which rely on the change of the plunger cavity content to realize oil absorption or discharge of oil by the reciprocating movement of the plunger in the plunger cavity. Plunger, the slippery boots, oil pan, cylinder body are important parts of the swash plate axial piston pump. Sliding boots is one of commonly used by high-pressure plunger pump form, it can meet the needs of the high pressure high speed;the oil distribution plate and cylinder directly affect of the pump efficiency and life span[1]. Because the swash plate axial piston pump has the advantages of compact structure, fewer parts, good manufacture ability, low cost, small volume, light weight, than the radial pump has the advantages of simple structure, easy to realize step less variable and convenient maintenance, it has been widely used in the industrial production.

• Periodical: Applied Mechanics and Materials (Volume 741)
• Pages: 517-520
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.741.517
• Online since: March 2015
• Authors: Hong Chuan Deng*, Yu Zhang, Hai Sheng Qian
• Keywords: ADAMS Simulation, Kinematic Analysis, Swash Plateaxial Piston Pump

References

[1] Kui Jinwen, Wang Hui. Hydraulic transmission[M]. Beijing. Northeastern University Press, (2001).

[2] QIN Yong. The actuality and development directions of hydraulic machines technology[J]. COAl MINE MACHINERY. 2002（11）10~12.

[3] Wen Desheng, Swash plate open type axial plunger pump, Beijing. CHINA MACHINE PRESS, 1993. 9.

[4] Guo Weidong. Virtual prototype technology and Adams application instance tutorial. Beijing. BEIHANG UNIVERSITY PRESS，2008. 6.

[5] Lebek A O. principles and Design of Mechanical Face Seals, TJ246. (1991).

[6] Peter Hattwig. Synthesis of ABS Hydraulic Systems. SAE, 930509.
