Path-Planning of Laser Quenching of 5-Axis Laser Machine Tool

Abstract:

This paper presents a path-planning method of laser tool in 5-axis laser quenching for complicated surface. In this method, two main factors are concerned which include: (1) Planning the CC paths on the complicated surface quenched to maintaining laser tool scanning speed constant easily in quenching process; (2) Diminishing the chord deviation between the actual value and its approximation by choosing different interpolation methods according to the curvature radius of CC points which is being quenched. This method effectively ensures the part’s laser quenching quality.

• Periodical: Applied Mechanics and Materials (Volume 741)
• Pages: 779-783
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.741.779
• Online since: March 2015
• Authors: Hong Wei Xu*, Hua Long Yu, Min Juan Li, Ju Wang
• Keywords: 5-Axis Laser Quenching, Chord Deviation, Curvature Radius, Path Planning
