Electric-Field Assisted Hydrothermal Growth of ZnO Nanorods on Flexible Substrate and their Strain Sensing Applications

Abstract:

This paper presents an electric-field assisted hydrothermal seedless synthesis of ZnO nanorods (NRs) on flexible polyimide (PI) substrate and their strain sensing applications. A three-electrode structure including top cathode and anode on PI substrate with a Copper layer on the back of PI (served as bottom gate) was fabricated with photolithography, sputtering and lift-off techniques. Hydrothermal growth of ZnO NRs on and between top cathode and anode (comb-like electrode-pair) was realized in Zn (NO₃)₂ and HMTA solution whilst an alternating current (AC) electric-field was applied onto the electrodes. The strain sensing properties of the fabricated ZnO NRs device were tested by measuring I-V characteristics of the device under different strains. From strain-free to 0.48% strain, the decrease ratio of the current flowing through the device reached 75% at a bias voltage of 1V.

• Periodical: Applied Mechanics and Materials (Volume 748)
• Pages: 49-52
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.748.49
• Online since: April 2015
• Authors: Xian Li Zong, Rong Zhu*, Chao Zhang
• Keywords: Electric-Field Assisted Growth, Flexible Strain Sensing, Hydrothermal Growth

References

[1] A. B. Djurisic, A. M. C. Ng, and X. Y. Chen, ZnO nanostructures for optoelectronics: Material properties and device applications, Progress in Quantum Electronics. 34 (2010) 191-259.

DOI: 10.1016/j.pquantelec.2010.04.001

[2] J. Y. Kim, H. Jeong, and D. J. Jang, Hydrothermal fabrication of well-ordered ZnO nanowire arrays on Zn foil: room temperature ultraviolet nanolasers, Journal of Nanoparticle Research. 13 (2011) 6699-6706.

DOI: 10.1007/s11051-011-0576-8

[3] B. Weintraub, Y. G. Wei, and Z. L. Wang, Optical Fiber/Nanowire Hybrid Structures for Efficient Three-Dimensional Dye-Sensitized Solar Cells, Angewandte Chemie-International Edition. 48 (2009) 8981-8985.

DOI: 10.1002/anie.200904492

[4] Y. Qin, X. Wang, and Z. L. Wang, Microfibre-nanowire hybrid structure for energy scavenging (vol 451, pg 809, 2008), Nature. 457 (2009) 340-340.

DOI: 10.1038/nature07628

[5] C. L. Hsu and K. C. Chen, Improving Piezoelectric Nanogenerator comprises ZnO nanowires by bending the flexible PET substrate at low vibration frequency, " Journal of Physical Chemistry C. 116 (2012) 9351-9355.

DOI: 10.1021/jp301527y

[6] X. N. Wen, W. Z. Wu, Y. Ding, and Z. L. Wang, Seedless synthesis of patterned ZnO nanowire arrays on metal thin films (Au, Ag, Cu, Sn) and their application for flexible electromechanical sensing, Journal of Materials Chemistry. 22 (2012).

DOI: 10.1039/c2jm31434g

[7] W. G. Zhang, R. Zhu, V. Nguyen, and R. S. Yang, Highly sensitive and flexible strain sensors based on vertical zinc oxide nanowire arrays, Sensors and Actuators a-Physical. 205 (2014) 164-169.

DOI: 10.1016/j.sna.2013.11.004

[8] D. Byrne, R. F. Allah, T. Ben, D. G. Robledo, B. Twamley, M. O. Henry, et al., Study of Morphological and Related Properties of Aligned Zinc Oxide Nanorods Grown by Vapor Phase Transport on Chemical Bath Deposited Buffer Layers, Crystal Growth & Design. 11 (2011).

DOI: 10.1021/cg200977n

[9] C. Soci, A. Zhang, B. Xiang, S. A. Dayeh, D. P. R. Aplin, J. Park, et al., ZnO nanowire UV photodetectors with high internal gain, Nano Letters. 7 (2007) 1003-1009.

DOI: 10.1021/nl070111x

[10] O. Lupan, G. A. Emelchenko, V. V. Ursaki, G. Chai, A. N. Redkin, A. N. Gruzintsev, et al., Synthesis and characterization of ZnO nanowires for nanosensor applications, Materials Research Bulletin. 45 (2010) 1026-1032.

DOI: 10.1016/j.materresbull.2010.03.027

[11] X. Zong, R. Zhu, Local control of ZnO nanorods growing on au surface with three-electrode microstructure, 2013 13th IEEE Conference on Nanotechnology (IEEE-Nano), (2013).

DOI: 10.1109/nano.2013.6720974

[12] X. Zong, R. Zhu, An electric-field assisted growth control methodology for integrating ZnO nanorods with microstructures, Nanoscale. (2014).

DOI: 10.1039/c4nr03184a
