Experimental Investigation on Electrical and Mechanical Characteristics of PVC Cable Insulation with Silica Nano Filler

Abstract:

Cables are an integral part of the power transmission and distribution network. As the voltage level increases, amount of insulation used in the cable increases. Therefore a need arises for a material with better insulation characteristics to be used in cables. The dielectric strength of cable insulation depends on many factors such as the existence of filler material in the insulation. In this work, laboratory studies on a new filler material for cable insulation have been conducted. The influence of Silicon dioxide (SiO₂) filler on the dielectric and mechanical properties of polyvinyl chloride (PVC) cable were analyzed. Comparison is made between the result of measurement and the actual value of the pure specimen. From the results, it is shown that the filler material has improved the dielectric and mechanical properties of the cable insulation.

• Periodical: Applied Mechanics and Materials (Volume 749)
• Pages: 159-163
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.749.159
• Online since: April 2015
• Authors: D. Edison Selvaraj*, R. Vijayaraj, U. Satheeshwaran, J. Nancy, C. Pugazhendhi Sugumaran, M. Raj Kumar, J. Ganesan, S. Geethadevi, S. Dinesh Kumar
• Keywords: Cable, Nanofiller, Partial Discharges, Silica

References

[1] Pugazhendhi Sugumaran. C, Experimental Investigation on Dielectric and Thermal Characteristics of Nanosized Alumina Filler Added Polyimide Enamel, Vol. 9, pp.978-983, JEET (2014).

DOI: 10.5370/jeet.2014.9.3.978

[2] Edison Selvaraj. D, et. al Estimation of Losses on 3Φ Nano Coated Induction Motor, Applied Mechanics and Materials Vol. 666 (2014) pp.213-217 (2014) Trans Tech Publications, Switzerland.

DOI: 10.4028/www.scientific.net/amm.666.213

[3] Edison Selvaraj. D, Pugazhendhi Sugumaran. C, Lieutenant Ganesan. J, Ramathilagam. J, Analysis of Dielectric and Thermal Properties of Polyamide Enamel Filled with Carbon Nano tubes, International Journal of Nano science, Vol. 12, Issue 3, June (2013).

DOI: 10.1142/s0219581x1350021x

[4] D. Edison Selvaraj, J. Ganesan. Experimental Analysis of Efficiency and Thermal Withstanding Capacity of Three Phase Squirrel Cage Induction Motor Coated with SiO2 & TiO2 Nano Composite Filled Enamel, International Journal of Engineering Sciences, Vol (2), No (4), 2013. pp.115-118.

DOI: 10.7753/ijsea0101.1004

[5] Edison Selvaraj, D., C. Pugazhendhi Sugumaran, and A. Sivaprakash Characterization of Electrical and Thermal Properties of Enamel Filled with Carbon Nanotubes, Proceedings of the Third International Conference on Trends in Information, Telecommunication and Computing. Springer New York, (2013).

DOI: 10.1007/978-1-4614-3363-7_78
