Comparative Efficiency of Artificial Neural Network to Predict Spring-Back Value in U-Bending Process of High Strength Steel

Abstract:

High strength steel (HSS) was used as raw material in the automotive industry, which required lightweight and high strength, such as chassis and etc. However, the strength and hardness of the steel are relatively high, leading to the low permeability and large spring-back occurring after forming operation. As a result, the work piece is not shaped desire. This research proposes neural network for predicts the spring back values, in U-bending process, that the materials were differences in mechanical properties, such as SPFH590 (JIS) and SPEC980Y (JIS). In the experiment, the input factors for predictable data consists as the punch radius (RP), die radius (Rd), clearance (Cl) and counter punch force (Fc). After that, the input data were analyzed relation with spring-back values by the Pearson Correlation of One-tailed. Next, It was selected by Leave-one-out and k-fold Cross validation (K-fold and LOOCV), to improve efficiency of the prediction process. Moreover, the result was a measurable performance with Root Mean Square Error (RMSE) technique, equal to 0.788 and 2.10 respectively. In the final analysis, the neural network is effective to predict the Spring-back values of SPFH590 (JIS) rather than SPEC 980Y (JIS) in U-bending process.

• Periodical: Applied Mechanics and Materials (Volume 749)
• Pages: 319-326
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.749.319
• Online since: April 2015
• Authors: Arkhom Songkroh*, Bhadpiroon Sresomroeng
• Keywords: Artificial Neural Network, Cross-Validation, High Strength Steel, Spring-Back, U-Bending Process

References

[1] Livatyali, H, Altan, T, Prediction and elimination of spring-back in straight flanging using computer aided design methods Part 1 Experimental investigations, Journal of Materials Processing Technology. 117(2001) 262-268.

DOI: 10.1016/s0924-0136(01)01164-5

[2] Livatyali , H , Altan , T , Wu.,H. C, Prediction and elimination of spring-back in straight flanging using computer aided design methods Part 2 FEM predictions and tool design, Journal of Materials Processing Technology. 120(2001) 348-354.

DOI: 10.1016/s0924-0136(01)01161-x

[3] S.H. Chang , J. M. Shin , Y. M. Heo and D. G. Seo, Spring-back characteristics of the tailor - welded strips in U- Bending, Journal of Materials Processing Technology. 130-131(2002) 14-19.

DOI: 10.1016/s0924-0136(02)00792-6

[4] M.V. Inamdar , P.P. Date , S.V. Sabnis, On the effects of geometric parameters on spring-back in sheets of five materials subjected to air vee bending, Journal of Materials Processing Technology, 123(2002) 459-463.

DOI: 10.1016/s0924-0136(02)00136-x

[5] Cho, J.R., Moon, S.J., Moon, Y.H. and Kang, S. S, Finite element investigation on spring-back characteristics in sheet metal Ubending process, Journal of Materials Processing Technology. vol. 141(2003) 109–116.

DOI: 10.1016/s0924-0136(03)00163-8

[6] Mori, K., Akita, K. and Abe, Y. 2007, Spring-back Behavior in Bending of Ultra-High-Strength Sheets Using CNC Servo Press, International Journal of Machine Tools and Manufacture, 47(2007) 321-325.

DOI: 10.1016/j.ijmachtools.2006.03.013

[7] B. Sresomroeng, V. Premanond, P. Kaewtatip, A. Khantachawana, N. Koga, Investigation of the Influences of Bending Die Clearance on Spring-back Values of High Strength Steel Using FEM, the proceeding of International Conference on Materials Processing Technology 2010 January 5-6, 2010, Bangkok, Thailand.

DOI: 10.1016/j.diamond.2010.02.008

[8] R. Ruffini, J. Cao, 1998, Using Neural Network for Spring-back Minimization in a Channel Forming Process, Journal of Materials & Manufacturing, 107(1998) 65-73.

[9] Recep Kazan, Mehmet Fırat, Aysun Egrisogut Tiryaki, 2009. Prediction of spring-back in wipe-bending process of sheet metal using neural network. Materials and Design. 30(2009) 418–423.

DOI: 10.1016/j.matdes.2008.05.033

[10] Zemin Fu, Jianhua Mo, Lin Chen, Wei Chen, Using genetic algorithm-back propagation neural network prediction and finite-element model simulation to optimize the process of multiple-step incremental air-bending forming of sheet metal, Materials and Design. 31(2010).

DOI: 10.1016/j.matdes.2009.06.019

[11] Sebahattin Tiryaki, Şükrü Özşahin, İbrahim Yıldırıma, 2013, Comparison of artificial neural network and multiple linear regression models to predict optimum bonding strength of heat treated woods, International Journal of Adhesion & Adhesives. 55(2013).

DOI: 10.1016/j.ijadhadh.2014.07.005
