CAD Based Drilling Simulations for Al7075

Abstract:

Drilling is considered to be one of the mostly used processes for holemaking. Researchers have followed three different approaches for its simulation i.e. analytic, experimental and numerical. Nowadays the direct access of scientists to the Application Programming Interface (API) of several CAD systems led to an increased number of finite element simulations based on CAD 3D models of drilling tools. The present paper uses a CAD system and via its API a kinematic model is created. Different tool parameters and cutting conditions are introduced; a series of 3D solid models for the tool, the workpieces and the undeformed chips are created and the resulted thrust forces are predicted in both the main edges and the chisel edge. The proposed methodology is experimentally verified using Al7075 for the workpiece and HSS for the tool material. In addition, it provides the basis for a series of new applications in other manufacturing processes based on CAD created geometries.

• Periodical: Applied Mechanics and Materials (Volume 760)
• Pages: 87-92
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.760.87
• Online since: May 2015
• Authors: Panagiotis Kyratsis*, Athanasios Manavis
• Keywords: Application Programming Interface (API), CAD, Drilling, Programming

References

[1] W. Grzesik, Advanced Machining Processes of Metallic Materials, Elsevier, ISBN: 978-0-08-044534-2, (2008).

[2] G. Mansour, A. Tsagaris, D. Sagris, CNC machining optimization by genetic algorithms using CAD based system, International Journal of Modern Manufacturing Technologies. 5(1) (2013) 75-80.

[3] D. Galloway, Some experiments on the influence of various factors on drill performance, Trans. A.S.M.E. 79 (1957) 191-231.

[4] Q. Sun, B. Gao, C. Yang, B. Chen, FEA of Micro-hole drilling in stainless steel based on DEFORMED 3D, Advanced Materials Research. 531 (2012) 566-570.

DOI: 10.4028/www.scientific.net/amr.531.566

[5] R. Muhammad, N. Ahmed, Y.M. Shariff, V.V. Silberschmidt, Effect of cutting conditions on temperature generated in drilling process: A FEA approach, Advanced Materials Research. 223 (2011) 240-246.

DOI: 10.4028/www.scientific.net/amr.223.240

[6] Y. Zhang, H. Zhang, Y. Ji, W. Li, Optimisation design of chip removal structure in the deep-hole drilling based on CAD/CFD, 4th International Seminar on Modern Cutting and Measurement Engineering. China (2010) doi: 10. 1117/12. 888616.

DOI: 10.1117/12.888616

[7] L. Yan, F. Jiang, A practical optimization design of helical geometry drill point and its grinding process, International Journal in Advanced Manufacturing Technology. 64 (2013) 1387-1394.

DOI: 10.1007/s00170-012-4109-0

[8] M.P. Yan, H. Shao, Study on high-speed drilling of SUS304 based on FEA, Advanced Materials Research. 18 (2011) 529-534.

DOI: 10.4028/www.scientific.net/amr.188.529

[9] O. Kienzle, H. Victor, Spezifische Shnittkraefte bei der Metall-bearbeitung, Werkstattstehnik und Maschinenbau. 47(5) (1957).
