Technological Process Design for the Flanged Parts Using a LabVIEW Application

Abstract:

The metal-forming processes provide a high degree of material utilization, a high working capacity, a high quality of the parts and so on. Taking in account the characteristics of these processes and the current requirements of the market economy, it is necessary to extend the research in the metal-forming field in order to develop new solutions that lead to optimization of the metal-forming technologies and, implicit, to obtain the best quality-price ratio. Also, the software for the simulation, data acquisition, data processing and computer aided design are necessary. This paper presents an application developed ​​using a graphical programming language called LabVIEW, through which, the dimensions of the sheet blank for the flanged parts are calculated based on the specifications of the work drawing, checks the hole flangeability and calculates the force required by the metal-forming processes.

• Periodical: Applied Mechanics and Materials (Volume 760)
• Pages: 81-86
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.760.81
• Online since: May 2015
• Authors: Paulina Spânu*, Bogdan Felician Abaza, Daniel Cazacu
• Keywords: Flanged Part, Force, Hole Flangeability, LabVIEW, Programming

References

[1] Sindilă, G., Tehnologii de fabricare prin presare la rece. Elemente de proiectare, Editura BREN, Bucureşti, România, (2001).

[2] Sindilă, G., Proiectarea tehnologiilor de prelucrare prin deformare plastică la rece, EDITURA BREN, Bucureşti, România, (2007).

[3] Sindilă, G., Purcărea M., Lăcătuș C., Rohan R., Căpățână N., Prelucrări prin deformare plastică la rece, Editura BREN, Bucureşti, România, (2009).

[4] Savu T. Arsenoiu L., Szuder A., Bazele programării în LabVIEW, Editura PRINTECH, București, (1999).

[5] Abaza B. Savu T. Spanu P, Indrumar de laborator – Algoritmi, PRINTECH, București, (2014).

[6] Information on http: /www. ni. com - National Instrumets.
