Effect of Nitrogen-to-Total Gas Flow Ratio on the Nanocomposite TiAlBN Coating

Abstract:

A nanocomposite TiAlBN (n-TiAlBN) coating has been successfully deposited via RF magnetron sputtering by varying the nitrogen-to-total gas flow ratio (R_N) at a substrate temperature of 300 °C. The coating was deposited on AISI 316 substrates using a single Ti-Al-BN hot-pressed target. The crystal phases, grain size and chemical composition of the coatings were measured using the glancing angle X-ray diffraction analysis (GAXRD) and X-ray photoelectron spectroscopy (XPS). The grains size of the n-TiAlBN coating was found to be within the range of 3.5 to 5.7 nm calculated using Scherrer’s formula. The n-TiAlBN coating reached a nitride saturated state at a higher R_N (e.g >15%) with the amount of boron concentration to be around 9 at. %. Further, reducing the R_N (e.g. 5%) has increased the boron concentration to 16.17 at. %. This paper shows that by carefully control the nitrogen-to-total gas flow ratio (R_N) in the n-TiAlBN coating, it indeed gives a significant effect on its crystallographic structure, grain size, and chemical compositions.

You might also be interested in these eBooks

Recent Technologies in Design, Management and Manufacturing

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 761)

Pages:

431-435

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.761.431

Citation:

Cite this paper

Online since:

May 2015

Authors:

Zulkifli Rosli*, Wai Loon Kwan, Mohd Warikh Abdul Rashid, Jariah Mohd Juoi, Nafarizal Nayan

Keywords:

GAXRD, Grain Size, Nanocomposite, RF Magnetron Sputtering, TiAlBN, XPS

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] C. Rebholz, M.A. Monclus, M.A. Baker, P.H. Mayrhofer, P.N. Gibson, A. Leyland, A. Matthews, Hard and superhard TiAlBN coatings deposited by twin electron-beam evaporation, Surf. Coat. Technol. 201 (2007) 6078-6083.

DOI: 10.1016/j.surfcoat.2006.08.121

Google Scholar

[2] M.A. Baker, M.A. Monclus, C. Rebholz, P.N. Gibson, A. Leyland, A. Matthews, A study of the nanostructure and hardness of electron beam evaporated TiAlBN coatings, Thin Solid Films 518 (2010) 4273-4280.

DOI: 10.1016/j.tsf.2009.12.109

Google Scholar

[3] C. Rebholz, J.M. Schneider, A.A. Voevodin, J. Steinebrunner, C. Charitidis, S. Logothetidis, A. Leyland, A. Matthews, Structure, mechanical and tribological properties of sputtered TiAlBN thin films, Surf. Coat. Technol. 113 (1999) 126-133.

DOI: 10.1016/s0257-8972(98)00840-8

Google Scholar

[4] D.V. Shtansky, K. Kaneko, Y. Ikuhara, and E.A. Levashov, Characterization of nanostructured multiphase Ti-Al-B-N thin films with extremely small grain size, Surf. Coat. Technol. 148 (2001) 206-215.

DOI: 10.1016/s0257-8972(01)01341-x

Google Scholar

[5] Z.M. Rosli, Z. Mahamud, W.L. Kwan, J.M. Juoi, K.T. Lau, Chemical composition analysis of TiAlBN nanocomposite coating deposited via RF magnetron sputtering, Key Eng. Mater. 594-595 (2014) 551-555.

DOI: 10.4028/www.scientific.net/kem.594-595.551

Google Scholar

[6] I. Zukerman, A. Raveh, Y. Shneor, R. Shneck, J.E. Klemberg-Saphieha, L. Martinu, Internal stress in TiAlBN at high temperatures, Surf. Coat. Technol. 201 (2007) 6161-6166.

DOI: 10.1016/j.surfcoat.2006.08.136

Google Scholar

[7] R. Avni, I. Fried, A. Raveh, I. Zukerman, Plasma surface interaction in PACVD and PVD systems during TiAlBN nanocomposite hard thin films deposition, Thin Solid Films 516 (2008) 5386-5392.

DOI: 10.1016/j.tsf.2007.07.093

Google Scholar

[8] J.K. Park, J.Y. Cho, H.T. Jeon, Y.J. Baik, Structure, hardness and thermal stability of TiAlBN coatings grown by alternating deposition of TiAlN and BN, Vacuum 84 (2010) 483-487.

DOI: 10.1016/j.vacuum.2009.10.013

Google Scholar

[9] D.C. Tsai, Y.L. Huang, S.R. Lin, S.C. Liang, F.S. Shieu, Effect of nitrogen flow ratios on the structure and mechanical properties of (TiVCrZrY)N coatings prepared by reactive magnetron sputtering, Appl. Surf. Sci. 257 (2010) 1361-1367.

DOI: 10.1016/j.apsusc.2010.08.078

Google Scholar

[10] Z.M. Rosli, W.L. Kwan, J.M. Juoi, N. Nayan, Z. Mahamud, Y. Yusuf, characterization of TiAlBN nanocomposite coating deposited via radio frequency magnetron sputtering using single hot-pressed target, Adv. Mater. Res. 626 (2013) 298-301.

DOI: 10.4028/www.scientific.net/amr.626.298

Google Scholar
