Identification of Damage for a Single and Double Edge Cracks in a Laminated Composite Beam by Using Harmonic Analysis

Abstract:

Composite structures are used in many critical engineering applications. In the recent times the research has been increased to identify the damage through the vibrational characteristics of the structure. There have been many theoretical and analytical studies on detection of damage involving analysis of the measured modal parameters, mainly the frequencies. The main objective of this paper is to use coupled response techniques for detecting damages in laminated composite cantilever beams with edge cracks using theoretical harmonic analysis. One method to observe the coupled modes is through the emergence of extra new peaks on a frequency response function plot that can be obtained by using standard vibration testing tools. An attempt has been made to develop a methodology by using coupled response measurements and this will happen to appear only when the structural member contains damage. Therefore, the coupled response can be used to monitor and it can be used to determine the damage existence. The frequency response plots are the only possible method to observe coupled response. The new resonance peaks are correlated to the coupled modes and the appearance of these peaks is the damage identification. The finite element analysis software application package ANSYS 12.0 has been used to obtain the new resonance peaks by using harmonic analysis of undamaged and damaged structures to enable comparisons that throw light on the presence of damages in the structure.

• Periodical: Applied Mechanics and Materials (Volumes 766-767)
• Pages: 14-20
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.766-767.14
• Online since: June 2015
• Authors: E.V.V. Ramanamurthy*
• Keywords: Composite Structures, Coupled Response Techniques, Extra New Peaks, Harmonic Analysis

References

[1] Baris Binici, Vibration of beams with multiple open cracks subjected to axial force, Journal of Sound and Vibration, , (2005), Vol. 287, p.277–295.

DOI: 10.1016/j.jsv.2004.11.010

[2] Cawley P, Woolfrey . M, and Adams R.D., Natural frequency measurements for the production quality-control of composites, Composites, (1985) , Vol. 26, pp.23-27.

DOI: 10.1016/0010-4361(85)90654-8

[3] Hamey et al., Experimental damage identification of carbon/epoxy composite beams using curvature mode shapes, , Structural Health Monitoring, (2004), Vol 3, No 4, pp.333-353.

DOI: 10.1177/1475921704047502

[4] Krawczuk M and W. M. Ostachowicz , Modelling And Vibration Analysis Of A Cantilever Composite Beam With A Transverse Open Crack, Journal Of Sound And Vibration , (1995) , Vol. 183(1), pp.69-89.

DOI: 10.1006/jsvi.1995.0239

[5] Kyriazoglou, C., Le Page, B. H., and Guild, F. J., Vibration damping for crack detection in composite laminates, Composites Part A: Applied Science and Manufacturing, 2004, Vol. 35, pp.945-953.

DOI: 10.1016/j.compositesa.2004.01.003

[6] Papadopoulos C. A and A D Dimaragonas, Coupled vibrations of a cracked shaft, Trans. ASME Journal of vibration and Acoustics, (1992), Vol. 114, pp.461-467.

[7] Sampaio, R. P., Maia, N. M. and Silva, J. M. , Damage detection using the frequency-response-function curvature method., Journal of Sound and Vibration, (1999), Vol. 226(5), pp.1029-1042.

DOI: 10.1006/jsvi.1999.2340

[8] Swamidas A S J and Y. Chen , Monitoring Crack Growth Through Change Of Modal Parameters, , Journal Of Sound And Vibration, (1995), 186(2), pp.325-343.

DOI: 10.1006/jsvi.1995.0452

[9] Thyagarajan, S. K., Schulz, M. J., Pai, P. F., and Chung, J., Detecting structural damage using frequency response functions, Journal of Sound and Vibration, 1998, 210(1), pp.162-170.

DOI: 10.1006/jsvi.1997.1308

[10] Ramanamurthy E.V.V., et al, A Damage Identification and Location by Using the Frequency Response function in a Composite Cantilever Beam, Proceedings of the 3rd World Conference on Applied Sciences, Engineering and Technology, 2014, 27-29 September 2014, Kathmandu, Nepal, ISBN 13: 978-81-930222-0-7, pp.453-457.

[11] Ramanamurthy E.V.V., et al., vibration analysis on a composite beam to identify damage and damage severity, International Journal of Engineering Science and Technology (IJEST), 2011, ISSN : 0975-5462 Vol. 3 No. 7, p. pp.5865-5888.
