Static Analysis of Load-Bearing Structure of a Transparent Roof

Abstract:

This paper deals with static analysis of load-bearing steel grid of a transparent roof. Ten structures with various spans (from 12.58 m to 30.08 m) and different heights (from 2.494 m to 7.471 m) have been modelled and analysed. The calculations were repeated for two common used types of the cross-sections - (60 x 40) mm and (60 x 60) mm. Permanent loads (the self-weight, the weight of glass panels) and variable loads (snow, wind) were taken into account. Obtained results were verified by four additional structures. The architects can use resultant graphs (the dimensions, maximum axial forces and maximum vertical displacements) in first stage of the design.

• Periodical: Applied Mechanics and Materials (Volume 769)
• Pages: 69-76
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.769.69
• Online since: June 2015
• Authors: Olga Ivankova, Lenka Konecna, Eva Vojtekova
• Keywords: Barrel Vault, Shell Structure, Static Analysis, Steel Grid, Structural Design, Transparent Roof

References

[1] Architekten von Gerkan, Marg und Partner: The History Museum in Hamburg (Germany), [online], [cit. 2014-06-24]. Available on: http: /www. gmp-architekten. com/projects/museum-of-hamburg-history-glass-roof. html.

DOI: 10.1515/9783868599527-024

[2] H. Schober, Glass roofs and glass facades, in: S. Behling, S. Behling, Glass – Structure and Technology in Architecture, Prestel Verlag, Műnchen, Germany, 1999, pp.68-73.

[3] Glass Roofing of a Museum Courtyard in Hamburg, in: Detail 1991, pp.33-35. ISSN 0011-9571.

[4] E. Vojtekova, Steel and glass – the materials for large transparent roofs, in: Eurostav: Odborny casopis z oblasti stavebnictva a architektury, 2004, Vol. 10, No. 7, pp.22-24. (in Slovak).

[5] T. Kolendowicz, Structural mechanics for architects, first ed., SNTL, Praha, 1984. (in Czech).

[6] O. Ivankova, M. Malast, Static and dynamic analysis of reinforced concrete shell structures and the optimalization of their structural design, in: Konstrukce pro stavebnictvi a strojirenstvi, 2005, Vol. 4, No. 4, pp.82-83. (in Slovak).

[7] A. Tesar, J. Melcer, Optimization control of bionics shell roofs subjected to snow skidding, in: International Journal for Numerical Methods in Engineering, John Willey & Sons, Ltd, Vol. 69, 2007, p.1446 – 1459.

DOI: 10.1002/nme.1815

[8] STN EN 1991-1-4. Eurocode 1: Actions on structures: Part 1-4: General actions. Wind actions. Slovensky ustav technickej normalizacie, 2007. (in Slovak).

DOI: 10.1680/dgte1.31524

[9] STN EN 1991-1-3. Eurocode 1: Actions on structures: Part 1-3: General actions. Snow load. Slovensky ustav technickej normalizacie, 2007. (in Slovak).
