Determination of the Cutting Moments at Teeth Tip in the Case of the Milling Cutter with Multiple Teeth

Abstract:

This paper presents experimental results for milling process using a six components dynamometer for complete mechanical actions measurement. The aim is the cutting moments determination and their evaluation on the milling cutter with multiple teeth during the cutting process. To know the cutting moments to the teeth of the tool, the instantaneous position of the teeth during milling process is determined. To achieve this purpose a calculation algorithm was developed to obtain the milling cutter teeth position respectively the moments at the tips of the teeth.

• Periodical: Applied Mechanics and Materials (Volume 772)
• Pages: 240-244
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.772.240
• Online since: July 2015
• Authors: Elena Luminița Olteanu*, Claudiu Florinel Bîșu
• Keywords: Cutting Moment, Dynamometer, Milling, Tool Position

References

[1] L.T. Tunc, O. Ozkirimli and E. Budak, Generalized cutting force model in multi-axis milling using a new engagement boundary determination approach, Int J of Adv Manuf Technol, (2014).

DOI: 10.1007/s00170-014-6453-8

[2] O. Tuysuz, Y. Altintas and H. -Y. Feng, Prediction of cutting forces in three and five-axis ball-end milling with tool indentation effect, Int J of Machine Tools and Manufacture, vol. 66, (2013).

DOI: 10.1016/j.ijmachtools.2012.12.002

[3] S. Campocassoa, J-Ph. Costesa, G. Fromentina, S. Bissey-Bretonb, G. Poulachona, Improvement of cutting forces modeling based on oriented cutting tests, Procedia CIRP 8, (2013).

DOI: 10.1016/j.procir.2013.06.090

[4] D. Toulouse, Y. Couétard, O. Cahuc, A. Gérard, An experimental method for the cutting process in three dimensions, Journal de Physique IV 7, C3, pp.21-26, (1997).

DOI: 10.1051/jp4:1997306

[5] O. Cahuc, D. Toulouse, Y. Couétard et A. Gerard, Un nouveau modele de la zone de contact outil copeau, Comptes Rendu Academie des Sciences Paris, France, IIb 328, p.1–4, (2000).

DOI: 10.1016/s1287-4620(00)88408-2

[6] Y. Couétard, Capteurs de forces à deux voies et application à la mesure d'un torseur de forces, Brevet francais - CNRS- 93403025. 5 N° d'ordre: 2240, (1993).

[7] O. Cahuc, C. Bisu and A. Gerard, Link between chips and cutting moments evolution, Journal of Advanced Materials Research, Vol. 423, pp.89-102, (2012).

DOI: 10.4028/www.scientific.net/amr.423.89

[8] C. Bisu, E. L. Olteanu, R. Laheurte, Ph. Darnis, O. Cahuc, Experimental approach on torsor dynamic analysis for milling process monitoring and diagnostic, Procedia CIRP ICME '12 - 8th, Elsevier (ISI), Proceedings paper, Vol. 12, pp.73-78, ISSN: 2212-8271, (2013).

DOI: 10.1016/j.procir.2013.09.014

[9] G. Albert, P. Darnis, J-Y K'nevez, R. Laheurte, O. Cahuc, Milling experimental model: adding the component of moment, Proceedings of IDMME - Virtual Concept, (2010).

[10] C. Bisu, E. L. Olteanu, C. Minciu and M. Zapciu, Torsor Evaluation of the Tooth During the Milling Process, Journal of Applied Mechanics and Materials, vol. 186, pp.194-199, (2012).

DOI: 10.4028/www.scientific.net/amm.186.194
