Optical Technique Using Nano-Spark Lightsource for Macro and Microscale Image Acquisition to Study Diesel Spray Atomization

Abstract:

Atomization and fuel-air mixing is an important process in diesel combustion. It directly affects the combustion and emission of diesel engine. Optical technique has the advantage of being unobtrusive in nature when compared to other technique. nanospark unit that has spark duration of 30ns was used as a lightsource to capture high resolution spray image using still film camera. The very short duration of the spark freeze the fast movement of the spray droplet, and sharp image of fuel droplet to be successfully captured by the camera, and then analyzed for sizing and spatial distribution. In addition, by using a more elaborate optical setup, dual image of the same spray can be captured, with a very short time interval between each of them. This provides the means to study dynamic behaviors of the diesel spray and also the droplets, as the progression of the spray and trajectory and velocity of the droplet can be analyze from these images. With the proposed optical technique and optical arrangement, microscopic detail of the diesel engine spray can be captured. Critical data such as droplet sizing can be extracted from this high resolution image. Furthermore, by introducing a more sophisticated optical arrangement coined dual-nano spark photography method, the droplet dynamic behaviors such as flying angle and velocity can be study.

• Periodical: Applied Mechanics and Materials (Volumes 773-774)
• Pages: 545-549
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.773-774.545
• Online since: July 2015
• Authors: Azwan Sapit*, Mohd Azahari Razali, M. Jaat, Akmal Nizam Mohammad, Amir Khalid, Bukhari Manshoor
• Keywords: Atomization, Diesel Spray, Fuel Droplets, Nanospark Photography, Optical Technique

References

[1] S. N. Soid and Z. a. Zainal, Spray and combustion characterization for internal combustion engines using optical measuring techniques – A review, Energy, vol. 36, no. 2, p.724–741, Feb. (2011).

DOI: 10.1016/j.energy.2010.11.022

[2] Hiro Hiroyasu and Masataka Arai, Structures of Fuel Sprays in Diesel Engines, SAE Paper, 900475, (1990).

DOI: 10.4271/900475

[3] Hiroyuki Hiroyasu and Toshikazu Kadota, Fuel Droplet Size Distribution in Diesel Combustion Chamber, Bulletin of JSME, vol. 19, no. 135, p.1064–1072, (1976).

DOI: 10.1299/jsme1958.19.1064

[4] Masanori Shimizu, Masataka Arai, and Hiroyuki Hiroyasu, Measurement of Breakup Length in High Speed Jet , Bulletin of JSME, vol. 27, no. 230, p.1709–1715, (1984).

DOI: 10.1299/jsme1958.27.1709

[5] Koch, Schmid, and Leipertz, Influence Of Injection Nozzle Parameters On The Spray Propagation And Combustion In A Di-Diesel-Engine, ICLASS 2006, Kyoto, Japan, (2006).

[6] H. Gen Fujimoto, H. Adachi, T. Yano, N. Marubayashi, T. Hori, and J. Senda, Spatial Droplets Size Distribution in a Diesel Spray Taken by Photography with Super High Resolution, ILASS – Europe 2010, 23rd Annual Conference on Liquid Atomization and Spray Systems, Brno, Czech Republic, September 2010, (2010).

DOI: 10.1299/jsmekansai.2010.85._1-20_

[7] A. Sapit, S. Nagayasu, Y. Tsuboi, Y. Nada, and Y. Kidoguchi, A Study on Improvement of Diesel Spray Characteristics Fueled by Rape-seed Oil, SAE Paper, 2011-32-0561, (2011).

DOI: 10.4271/2011-32-0561

[8] Marie Bysveen, Terje Almas, Kjell Arne Ulvund, Atle Jorgensen, and Frode Kvinge, Development of a Shadowgraph Image Technique Describing the Fuel Spray Behavior in a Rapid Compression Machine, SAE Paper, 2004-01-2934, (2004).

DOI: 10.4271/2004-01-2934

[9] Choongsik Bae and Jinsuk Kang, The structure of a break-up zone in the transient diesel spray of a valve-covered orifice nozzle, International Journal of Engine Research, vol. 7, no. 4, p.319, Jan. (2006).

DOI: 10.1243/14680874jer04805
