Etch Performance of KRF Excimer Laser Micromachining Characterization on Silicon Material

Abstract:

Excimer laser micromachining enables us to overcome the conventional lithography-based microfabrication limitations and simplify the process of creating three dimensional (3D) microstructures.The objective of this study is to investigate the relation between the number of laser pulses, number of laser passes through the channel of ablation site and their etch performance. Parameters such as frequency, fluence and velocity were retained as constants. In this paper, we present a parametric characterization study on silicon using KrF excimer laser micromachining. From the result, the etch rate change were recorded as the two major laser parameters (Number of laser pulses and number of laser passes) were varied. Both parameters were showing declination profile however from comparing both graphs, it showed that etch rate dropped more steeply when varied number of laser passes rather than number of pulses.

• Periodical: Applied Mechanics and Materials (Volume 780)
• Pages: 29-32
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.780.29
• Online since: July 2015
• Authors: M.Z. Zainol*, Yufridin Wahab, H. Fazmir, A.F.M. Anuar, S. Johari, M. Najmi, M. Mazalan
• Keywords: Excimer Laser, KrF, Krypton Fluoride, Silicon

References

[1] M. J. Madou, Fundamentals of microfabrication: the science of miniaturization: CRC press, (2002).

[2] K. Liu, Z. NiCkolov, and J. Oh, KrF excimer laser micromachining of MEMS materials: characterization and applications, Journal of Micromechanics and Microengineering, vol. 22, p.015012, (2012).

DOI: 10.1088/0960-1317/22/1/015012

[3] J. Kim and X. Xu, Excimer laser fabrication of polymer microfluidic devices, Journal of Laser Applications, vol. 15, pp.255-260, (2003).

DOI: 10.2351/1.1585085

[4] M. Lapczyna and M. Stuke, Rapid prototype fabrication of smooth microreactor channel systems in PMMA by VUV laser ablation at 157 nm for applications in genome analysis and biotechnology, in MRS Proceedings, 1998, p.143.

DOI: 10.1557/proc-526-143

[5] R. Vaidya, L. M. Tender, G. Bradley, M. J. O'Brien, M. Cone, and G. P. López, Computer‐Controlled Laser Ablation: A Convenient and Versatile Tool for Micropatterning Biofunctional Synthetic Surfaces for Applications in Biosensing and Tissue Engineering, Biotechnology progress, vol. 14, pp.371-377, (1998).

DOI: 10.1021/bp980039w

[6] H. Sato and S. Nishio, Polymer laser photochemistry, ablation, reconstruction, and polymerization, Journal of Photochemistry and Photobiology C: Photochemistry Reviews, vol. 2, pp.139-152, (2001).

DOI: 10.1016/s1389-5567(01)00015-6
