Simulation of Closed Loop Electro-Hydraulic Actuator Using PID Based on AMESim

Abstract:

Electro-hydraulic actuators are widely used in motion control application. Position control using hydraulic systems is widely applied in several engineering fields. However, their design is not a simple task since it is necessary to observe their behavior according to control theory.This paper represents an implementation of motion control of electro-hydraulic actuator by using PID controller. The objective of this study was to obtain Physical model of an electro-hydraulic actuator using system identification technique by estimating model using AMESim and provide the electro-hydraulic system which depends the hydraulic actuators to meet the motion control system demands.The physical model of electro-hydraulic actuator is established; it was modeled and simulated by using advanced performance modeling and simulation environment AMESim. It is shown that using AMESim to model and simulate performance more directly and veritably, and can complete the design task accurately and quickly.

• Periodical: Applied Mechanics and Materials (Volumes 789-790)
• Pages: 865-872
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.789-790.865
• Online since: September 2015
• Authors: Mehmood Qaiser*
• Keywords: AMEsim, Electro-Hydraulic Actuator, PID, Position Control

References

[1] E.A. Parr, Industrial Control Handbook, Volume 2, BSP Professional Books, (1987).

[2] Y. Cervantes, A.R. Jose, On the PID tracking control of robot manipulators. System & Control Letters, vol. 42, no. 3, pp.37-46, (2001).

DOI: 10.1016/s0167-6911(00)00077-3

[3] R. Ghazali, Y.M. Sam, M.F. Rahmat, A.W.I.M. Hashim and M. Zulfatman, Sliding Mode Control with PID Sliding Surface of an Electro-hydraulic Servo System, Australian Journal of Basic and Applied Sciences, 4 (10), 2 pp.4749-4759, (2010).

DOI: 10.1109/scored.2010.5704009

[4] H. -M. Chen, J. -C. Renn, J. -P. Su, Sliding mode control with varying boundary layers for an electro-hydraulic position servo system, International Journal of Advanced Manufacturing Technology, vol. 26, pp.117-123, (2005).

DOI: 10.1007/s00170-004-2145-0

[5] Y. -H. Li, X. -Y. Chen, AMESim-based Simulation and Optimization of Hydraulic Cylinder System, Journal of Wuhan University of Science and Technology, 34, pp.215-218, (2011).

[6] X. -C. Liu, et al. Modeling and Simulation of Threestage Electro-hydraulic Servo Valve Based on AMESim, Machine and Hydraulic, 36, pp.135-136, (2008).
