Skid Control of Small Electric Vehicles with In-Wheel Motors (Effect of ABS and Regenerative Brake Timing Control on Emergency Braking)

Abstract:

This paper presents an active safety device for skid control of small electric vehicles with in-wheel motors. Due to the space limitation on the driving tire, a mechanical brake system was installed rather than hydraulic brake system. For the same reason, anti-lock brake system (ABS) that is a basic skid control method cannot be installed on the driving tire. During braking on icy road or emergency braking, the tire will be locked and the vehicle is skidding. To prevent tire lock-up and vehicle from skidding, we proposed the combination of ABS and regenerative brake timing control. The hydraulic unit of ABS is installed on the non-driving tire while the in-wheel motors on the driving tire will be an actuator of ABS to control the regenerative braking force. The performance of the ABS and regenerative brake timing control on the emergency braking situation is measured by the simulation. The simulation result shows that the combination of ABS and regenerative brake timing control can prevent tire lock-up and vehicle from skidding.

• Periodical: Applied Mechanics and Materials (Volumes 789-790)
• Pages: 927-931
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.789-790.927
• Online since: September 2015
• Authors: Mohamad Heerwan bin Peeie, Hirohiko Ogino, Yoshio Yamamoto
• Keywords: Anti-Lock Brake System (ABS), Hydraulic-Mechanical Hybrid Brake System, In-Wheel Motors, Regenerative Brake, Skid Control, Small Electric Vehicles

References

[1] S J Clegg : A review of Regenerative Braking Systems, Transaction of Institute for Transport Studies, University of Leeds, (1996), pp.5-8.

[2] Z. Ding, L. He and Z. Dong : Modeling and Testing of Low-Speed Electric Vehicle, Proceedings of the International Conference on Electric Information and Control Engineering (ICEICE), (2011), pp.2355-2357.

DOI: 10.1109/iceice.2011.5777010

[3] M.I. Ishak, H. Koduki and H. Ogino: Research on anti-lock braking system of a 2 wheel small electric vehicle with hydraulic-mechanical hybrid brake system, Proceedings of the 2010 JSAE Kanto International Conference of Automotive Technology for Young Engineers (ICATYE), (2010).

DOI: 10.1299/jsmemecj.2011._g100024-1

[4] Z. Cai, C. Ma and Q. Zhao: Acceleration to Torque Ratio Based Anti-kid Control for Electric Vehicles, International Conference on Mechatronics and Embedded System and Applications, (2010), pp.577-581.

DOI: 10.1109/mesa.2010.5552020

[5] K. Fuji and H. Fujimoto: Traction control based on slip ratio estimation without detecting vehicle speed for electric vehicle, Proceedings of the 2007 Power Conversion Conference, (2007), pp.688-693.

DOI: 10.1109/pccon.2007.373040

[6] X. Wu, C. Ma, M. Xu, Q. Zhao and Z. Cai : Single-Parameter Skidding Detection and Control Specified for Electric Vehicles, Transactions of the Journal of the Franklin Institute, (2014), pp.1-16.

DOI: 10.1016/j.jfranklin.2014.07.007

[7] K. Cakir and A. Sabanovic : In-wheel Motor Design for Electric Vehciles, Proceedings of the 2006 9th International Workshop on Advanced Motion Control (AMC 2006), (2006), pp.613-618.

DOI: 10.1109/amc.2006.1631730
