Research on Wear Mechanism of Solid Lubrication Bearing in Vacuum Environment

Abstract:

The wear mechanism of solid lubrication bearing in vacuum environment was researched. It experiment on the angular contact ball bearing of sputter-deposited MoS2 solid lubrication coating in bearing friction test device, and the time-varying characteristics of bearing temperature and vibration can be got. The MoS2 solid lubrication coating on bearing surface was gradually wear in the process of bearing rotation, and the temperature and vibration of bearing were increased. The transfer membrane was formation in bearing raceway with the increase of bearing rotation. The transfer membrane accumulation occurs due to uneven thickness of MoS2 solid lubrication coating, and the bearing produce serious vibration. Through the microstructure observation and energy spectrum analysis of the bearing surface, it finds there are pitting caused by fatigue wear and scratch caused by abrasive wear after test. The test result indicate that the wear mechanism of solid lubrication bearing in vacuum environment were fatigue wear of solid lubrication coating caused by steel ball circularly rolling and abrasive wear caused by steel ball sliding.

• Periodical: Applied Mechanics and Materials (Volume 798)
• Pages: 424-429
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.798.424
• Online since: October 2015
• Authors: Xiao Ming Lai*, Jian Chao Han, Peng Gao, Jian Jun Qu, Yun Li, Chun Lin Tan, Jiang Jiang
• Keywords: Solid Lubrication, Time-Varying Characteristics, Vacuum Environment, Wear Surface Morphology

References

[1] S. Fouvry, C. Paulin. An effective friction energy density approach to predict solid lubricant friction endurance: Application to fretting wear[J]. Wear, 2014, 319 (1-2): 211-226.

DOI: 10.1016/j.wear.2014.07.009

[2] LUO Jun, WANG Yundong, CAI Zhenbing, MO Jiliang. Rotational Fretting Wear Characteristics of Bonded Molybdenum Disulfide Solid Lubrication Coating[J]. Journal of Mechanical Engineering, 2012, 48 (17): 100-105.

DOI: 10.3901/jme.2012.12.100

[3] Hu K H, Liu M, Wang Q J. Tribological properties of molybdenum disulfide nanosheets by monolayer restacking process as additive in liquid paraffin [J]. Tribology International, 2009, 42: 33-39.

DOI: 10.1016/j.triboint.2008.05.016

[4] Rapoport L, Leshchinsky V, Volovik Y. Modification of contact surfaces by fullerene-like solid lubricant nanoparticles[J]. Surface and Coatings Technology, 2003, 405-412.

DOI: 10.1016/s0257-8972(02)00729-6

[5] Guogang Tang, Jing Zhang, Changchao Liu, Du Zhang. Synthesis and tribological properties of flower-like MoS2 microspheres[J]. Ceramics International, 2014, 40(8): 11575-11580.

DOI: 10.1016/j.ceramint.2014.03.115

[6] Hu K H, Hu X G, Xu Y F. The effect of morphology on the tribological properties of MoS2 in liquid paraffin[J]. Tribology Letters, 2010, 40(1): 155-165.

DOI: 10.1007/s11249-010-9651-z

[7] N Hiraoka. Wear life mechanism of journal bearings with bonded MoS2 lubricating films in air and vacuum[J]. Wear, 2002, 249(10-11): 1014-1020.

DOI: 10.1016/s0043-1648(01)00845-6

[8] Imène Lahouij, Béatrice Vacher, Jean-Michel Martin, Fabrice Dassenoy. IF-MoS2 based lubricants: Influence of size, shape and crystal structure[J]. Wear, 2012, 296(1-2): 558-567.

DOI: 10.1016/j.wear.2012.07.016

[9] Risdon J J. Evaluation of MoS2 in newer grease thicker systems[J]. NLGI Spokesman, 1986, 50(6): 211-214.

[10] YE Yinping, CHEN Jianmin, ZHOU Huidi. An Investigation of Load-carrying and Speed-resistant Capacities of Bonded MoS2 Solid Lubricating Films[J]. Journal of Materials Engineering, 2008(z1): 1-6.

[11] LIN Guanyu, WANG Shurong, WANG Lipeng. Friction Performance of Ball Bearings Coated with MoS2 Compound Film in Vacuum[J]. Tribology, 2008, 28 (4): 377-380.

[12] WAN Zhihua, ZHENG Jun, ZHAO Yunping, ZHOU Hui. Analysis of Wear and Lubrication Failure during the Wear 1ife-Tests of Sputtering MoS2/Sb2O3 Composite Films[J]. Lubrication Engineering, 2011, 36 (12): 45-49.

[13] WEN Lingfeng. Study on Damage Mechanism of Solid Lubrication Bearing in Vacuum Environment[D]. Harbin: Harbin Institute of Technology, (2009).
