Finite Element Analysis of Casing Material Behavior in Steam Injection Well Operations

Abstract:

Casing design is one of the most important parts of the well planning in the oil and gas industry. Various factors affecting the casing material needs to be considered by the drilling engineers. Wells partaking in thermal oil recovery processes undergo extreme temperature variation and this induces high thermal stresses in the casings. Therefore, forecasting the material behavior and checking for failure mechanisms becomes highly important. This paper uses Finite Element Methods to analyze the behavior two of the frequently used materials for casing - J55 and L80 steels. Modeling the casing and application of boundary conditions are performed through Ansys Workbench. Effect of steam injection pressure and temperature on the materials is presented in this work, indicating the possibilities of failure during heating cycle. The change in diameter of the casing body due to axial restriction is also presented. This paper aims to draw special attention towards the casing design in high temperature conditions of the well.

• Periodical: Applied Mechanics and Materials (Volumes 799-800)
• Pages: 196-200
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.799-800.196
• Online since: October 2015
• Authors: Abhilash M. Bharadwaj*, Sonny Irawan, Saravanan Karuppanan, Mohamad Zaki bin Abdullah, Ismail bin Mohd Saaid
• Keywords: Casing Design, FEA Injection, J55 Steel, L80 Steel, Material Behavior, Steam Injection

References

[1] K.C. Hong: Steamflood Reservoir Management Thermal Enhanced Oil Recovery. Pennwell Publishing Company, Oklahoma.

[2] P. G. Willhite and W. K. Dietrich, Design Criteria for Completion of Steam Injection Wells, The Journal of Petroleum Technology, January edition, Pg. 15-21, (1967).

DOI: 10.2118/1560-pa

[3] K. Maruyama, E. Tsuru, M. Ogasawara, Y. Inoue and E. J. Peters, An Experimental Study of Casing Performance Under Thermal Cycling Conditions, SPE Drilling Engineering, June edition, Pg. 156-164, (1990).

DOI: 10.2118/18776-pa

[4] J. Wu and M. E. Knauss, Casing Temperature and Stress Analysis in Steam-Injection Wells, SPE International Oil & Gas Conference and Exhibition, Beijing, China, (2006).

DOI: 10.2118/103882-ms

[5] J. C. R. Placido, P. Jr. Adema, L. Paulo, I. P. Pasqualion, and S. F. Estefan, StressAnalysis of Casing String Submitted to Cyclic Steam Injection, Fifth Latin American and Caribbean Petroleum Engineering Conference and Exhibition, Rio de Janeiro, Brazil, (1997).

[6] C. Teodoriu and G. Falcone, Comparing Completion Design in Hydrocarbon and Geothermal Wells: The need to evaluate the integrity of casing connections subject to thermal stresses, Geothermics, vol. 38, Pg. 238-246, (2009).

DOI: 10.1016/j.geothermics.2008.11.006

[7] G. B. Lepper, Production Casing Performance In a Thermal Field, Journal of Canadian Petroleum Technology, September edition; Vol. 37, No. 9, (1998).

[8] J. Wu, M. E. Knaussand T. Kritzler, Casing Failures in Cyclic Steam Injection Wells, IADC/SPE Asia Pacific Drilling Technology Conference and Exhibition, Jakarta, Indonesia, (2008).

DOI: 10.2118/114231-ms

[9] J. Wu, M. E. Gonzalez, and N. Hosn, Steam-Injection Casing Design, SPE Western Regional Meeting held in Irvine, CA, U.S. A, (2005).

[10] Information on www. contalloy. com/materials/alloy-steelretrieved on 21 May (2014).

[11] J. Norwinka, T. Kaiser and B. Lepper, Strain-based Design of Tubulars for Extreme-Service Wells, SPE Drilling and Completion, December edition, Pg. 353-360, (2008).

DOI: 10.2118/105717-pa

[12] D. D. Acqua, M. Hodder and T. M. V. Kaiser, Burst and Collapse Responses of Production Casing in Themal Applications, SPE Drilling and Completion, March edition, Pg 93-104, (2013).

DOI: 10.2118/151810-pa
