Use of External Testing Methods to Assess Damage on Rockfall Protection Structures

Abstract:

This paper deals with the evaluation of damage due to boulder impact on rockfall protection embankment thanks to external methods. A 4 m high, 8 m long three layered structure is built using cells filled with different material according to their location in the structure. The structure is impacted by a 6500 kg spherical boulder with a maximal impact energy of 2000 kJ. The behaviour of the structure is first investigated using topographic surveys. Then, the results are compared with geophysical measurements. Results show that a low-energy impact leads to (i) the densification of both front and inner-layers associated with the swelling of the materials of the rear layer in the impact plane, and (ii) to the readjustment of internal materials which induces a local densification in a plane offset of 2 m. A high-energy impact induces large deformations on both inner and rear layers. These results are confirmed by seismic velocities which decrease with successive impacts.

• Periodical: Applied Mechanics and Materials (Volume 82)
• Pages: 704-709
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.82.704
• Online since: July 2011
• Authors: Adeline Heymann, Marielle Collombet, Stéphane Lambert, Philippe Gotteland
• Keywords: Cellular Structure, Field Test, Geophone, Impact

References

[1] S. Lambert, P. Gotteland, F. Nicot, Experimental study of the impact response of geocells as components of rockfall protection embankments, Natural Hazards and Earth Systems Science, Vol. 9, (2009) pp.459-467.

DOI: 10.5194/nhess-9-459-2009

[2] A. Heymann, S. Lambert, E. Haza-Rozier, G. Vinceslas, P. Gotteland: An experimental comparison of real–scale rockfall protection sandwich structures, proceedings of SUSI 2010, Tallinn, Estonia, (2010)

DOI: 10.2495/su100021

[3] F. Bourrier, P. Gotteland, F. Nicot, S. Lambert in A model for rockfall protection structures based on multi-scale approach. Geoflorida, West Palm Beach (2010).

DOI: 10.1061/41095(365)231

[4] A. Breugnot, P. Gotteland, P. Villard in Numerical modelling of impacts on granular materials with a combined discrete – continuum approach. Proceedings of the seventh European conference on NUmerical Methods in Geotechnical Engineering (NUMGE 2010), Trondheim, Norway, 2-4 (2010), pp.477-482.

DOI: 10.1201/b10551-89

[5] F. Nicot, P. Gotteland, D. Bertrand, S. Lambert, Multi-scale approach to geo-composite cellular structures subjected to impact, International Journal for Numerical and Analytical Methods in Geomechanics, Vol. 31, (2007). pp.1477-1515.

DOI: 10.1002/nag.604
