Real Scale Experiments on Rockfall Protection Barriers

Abstract:

In the rockfall protection barriers, the role of the net is to diffuse the efforts to the braking devices which absorb the energy and slow down the velocity of the block. An innovative braking device working by the buckling of metallic tubes is developed by quasi-static and dynamic tests. Real scale experiments on the entire structure are done and presented here. These tests are performed as the recommendations of the new Guideline for European Technical Approval concerning the falling rock protection kits, named ETAG 27.

• Periodical: Applied Mechanics and Materials (Volume 82)
• Pages: 734-739
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.82.734
• Online since: July 2011
• Authors: Ayman Trad, Ali Limam, Philippe Robit
• Keywords: Dynamic, Energy, Impact, Orthotropic, Protection, Real Scale Experiments, Rockfall

References

[1] G. Hearn, R.K. Barret, H.H. Henson, "Development of Effective Rockfall Barriers". Journal of transportation engineering, vol. 121, pp.507-516 (1995).

DOI: 10.1061/(asce)0733-947x(1995)121:6(507)

[2] D. Peila, S. Pelizza, F. Sassudelli, "Evaluation of Behaviour of Rockfall Restraining Nets by Full Scale Tests". Rock Mechanics and Rock Engineering, vol. 31, pp.1-24 (1998).

DOI: 10.1007/s006030050006

[3] W. Gerber, "Field testing of rockfall protection barriers a comparison between inclined ropeway and vertical crane testing". Tech. rep., Swiss agency of environment, Forests and Landscape and the swiss federal research institute WSL (2001).

[4] D. Peila, C. Ronco, "Technical Note: Design of rockfall net fences and the new ETAG 027 European guideline". Natural Hazards and Earth System Sciences, vol. 9, pp.1291-1298 (2009).

DOI: 10.5194/nhess-9-1291-2009

[5] G. Gottardi, L. Govoni, "Full-scale modeling of falling rock protection barriers". Rock Mech Rock Engng, vol. 43, pp.261-274, (2010).

DOI: 10.1007/s00603-009-0046-0

[6] A. Trad, A. Limam, P. Robit, "Les filets pare-pierres, approche expérimentale et numérique par la MEF". Géomécanique des instabilités rocheuses: du déclenchement à l'ouvrage, Traité MIM, Chapitre 10, 39 p, (2010).

[7] D. Bertrand, A. Trad, R. Chauvel, A. Limam, "Discrete element simulation of an innovative metallic net dedicated to rockfall protection: a multi-scale approach". 3rd Euro Mediterranean Symp. on Advances in Geomaterials and Structures, Djerba (Tunisia), 8 p, 10 to 12 May 2010.

[8] A. Trad, A. Limam, P. Robit, "New energy dissipating device for rockfall protection barriers". 3rd Euro Mediterranean Symp. on Advances in Geomaterials and Structures, Djerba (Tunisia), 8 p, 10 to 12 May 2010.

[9] ETAG 27, Guideline for European Technical Approval of Falling Rock Protection Kits, 53 p, (2008).
