Prediction of Dissipative Properties of Flax Fibers Reinforced Laminates by Vibration Analysis

Abstract:

This study proposes an experimental-numeric method to identify the viscoelastic properties of flax fibres reinforced composite laminate (flax/epoxide). The used method consists in identifying the evolutions of both loss factor and stiffness when vibrational frequency changes. In this way, several free-free symmetrically guided beams are excited on a dynamic range of 10 to 4000 Hz with sweep sine excitation focused around the 4-first’s modes. Fractional derivative Zener model is used to identify the on-axis ply complex moduli and describe the laminate dissipative linear behavior with the classical laminate theory. Results obtained on a quasi-isotropic laminate show that this model adequately predicts the vibrational behavior of the tested laminates.

• Periodical: Applied Mechanics and Materials (Volume 822)
• Pages: 411-417
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.822.411
• Online since: January 2016
• Authors: Marouane Belaïd*, Stéphane Fontaine, Ali El Hafidi, Papa Benoît Piezel, Papa Birame Gning
• Keywords: Damping, Frequency, Laminates, Vibration, Viscoelasticity

References

[1] F. Duc, P. E. Bourban , J. -AE. Månson, The role of twist and crimp on the vibration behaviour of flax fibre composites, Composites Science and Technology 102 (2014) 94-99.

DOI: 10.1016/j.compscitech.2014.07.004

[2] J. -M. Berthelot, Y. Sefrani Damping analysis of unidirectional glass and Kevlar fibre composites, Composites science and technology 64(9) (2004), 1261-1278.

DOI: 10.1016/j.compscitech.2003.10.003

[3] R. G. Ni, R. D. Adams, The damping and dynamic moduli of symmetric laminated composite beams—theoretical and experimental results, Journal of Composite Materials 18(2) (1984) 104-121.

DOI: 10.1177/002199838401800202

[4] P. Kumar, R. Chandra, S. P. Singh, Measurement of Damping of Fiber Reinforced Composite Material. Journal of Materials Science and Engineering B 1(5) (2011) 555-564.

[5] A. B. Schultz, S. W. Tsai, Measurements of complex dynamic moduli for laminated fiber-reinforced composites, Journal of Composite Materials 3(3) (1969) 434-443.

DOI: 10.1177/002199836900300308

[6] R. M. Crane, J. W. Jr Gillespie, Characterization of the vibration damping loss factor of glass and graphite fiber composites, Composites Science and Technology 40(4) (1991) 355-375.

DOI: 10.1016/0266-3538(91)90030-s

[7] R. M. Crane, J. W. Jr. Gillespie, Analytical model for prediction of the damping loss factor of composite materials, Polymer Composites 13(3) (1992) 179–190.

DOI: 10.1002/pc.750130306

[8] J. H. Yim, J. W. Jr Gillespie, Damping characteristics of 0 and 90 AS4/3501-6 unidirectional laminates including the transverse shear effect, Composite structures, 2000, vol. 50, no 3, pp.217-225.

DOI: 10.1016/s0263-8223(00)00087-8

[9] N. W. Tschoegl, The phenomenological theory of linear viscoelastic behavior: an introduction, Berlin: Springer-Verlag, (1989).

[10] T. Pritz, Analysis of four-parameter fractional derivative model of real solid materials, Journal of Sound and Vibration 195(1) (1996) 103-115.

DOI: 10.1006/jsvi.1996.0406

[11] Z. Hashin, Complex moduli of viscoelastic composites — II. Fiber reinforced materials, International Journal of Solids and Structures 6(6) (1970) 797-807.

DOI: 10.1016/0020-7683(70)90018-1

[12] J-L. Wojtowicki, L. Jaouen, R. Panneton, New approach for the measurement of damping properties of materials using the Oberst beam, Review of Scientific Instruments 75(8) (2004) 2569-2574.

DOI: 10.1063/1.1777382
