Microgrinding with Diamond Electroplated Tools and with Single-Disk Lapping Kinematics

Abstract:

New tools for flat grinding are the subject of the paper. Electroplated diamond tools with different grains - D64 and D107 - were used in a modified single-disc lapping machine configuration. The results from flat grinding, such as the material removal rate (MMR), surface roughness and plane-parallelism are presented in the paper. Apart from ceramic samples, the additional experiments were carried out on cemented carbide workpieces (H10S) with the use of a diamond electroplated tool (D64). SEM microscopic images of unworn and worn active tool surface are presented with abrasive grains worn by attrition and cavities in the nickel bond after the grains pull out.

• Periodical: Applied Mechanics and Materials (Volume 831)
• Pages: 25-32
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.831.25
• Online since: April 2016
• Authors: Adam Barylski, Mariusz Deja*
• Keywords: Abrasive Machining, Finishing Processes, Lapping Kinematics

References

[1] Barylski A., Deja M., Heinrich M., Hoghe T., Ikken B., Uhlmann E.: Grinding of cemented carbides with planetary kinematics, Developments in Mechanical Engineering, 2009, Vol. 3, pp.65-71.

[2] Barylski A., Deja M.: Influence of Flat Lapping Kinematics on Machinability of Ceramics, Solid State Phenomena, 2013, Vol. 199, pp.615-620.

DOI: 10.4028/www.scientific.net/ssp.199.615

[3] Barylski A., Deja M.: Microgrinding of flat surfaces on single-disc lapping machine, Int. J. Machining and Machinability of Materials, 2009, Vol. 5, Nos. 2/3, p.245–267.

DOI: 10.1504/ijmmm.2009.023393

[4] Beyer P., Marc van Ravenzwaaij: Innovative flat honing with vitrified-bond grinding and conditioning tools, Industrial Diamond Review, 2005, Vol. 4, pp.47-50.

[5] Sanchez L.E.A., Jun N.Z.X., Fiocchi A.A.: Surface finishing of flat pieces when submitted to lapping kinematics on abrasive disc dressed under several overlap factors, Prec. Engineering, 2010, Vol. 35, pp.355-363.

DOI: 10.1016/j.precisioneng.2010.09.012

[6] Shi Z., Malkin S.: Wear of electroplated CBN wheels, ASME J. Manufacturing Science and Engineering, 2006, Vol. 128, pp.110-118.

DOI: 10.1115/1.2122987

[7] Shi Z., Malkin, S.: An investigation of grinding with electroplated CBN wheels, Annals of the CIRP, 2003, Vol. 52, No. 1, pp.267-270.

DOI: 10.1016/s0007-8506(07)60581-2

[8] Upadhyaya R.P., Fiecoat J.H.: Factors Affecting Grinding Performance with Electroplated CBN Wheels, CIRP Annals - Manufacturing Technology, 2007, Volume 56, Issue 1, pp.339-342.

DOI: 10.1016/j.cirp.2007.05.078

[9] Hwang T.W., Evans C.J., Malkin S.: High speed grinding of silicon nitride with electroplated diamond wheels, part 2: wheel topography and grinding mechanisms, J. Manufacturing Science and Engineering, 2000, Vol. 122, No. 1, pp.42-50.

DOI: 10.1115/1.538909

[10] Hwang T.W., Evans C.J., Whitenton E.P., Malkin S.: High speed grinding of silicon nitride with electroplated diamond wheels, part 1: wear and wheel life, J. Manufacturing Science and Engineering, 2000, Vol. 122, No. 1, pp.32-41.

DOI: 10.1115/1.538908

[11] Deja M.: Vertical vibration reduction and audible sound analysis in surface grinding with electroplated tools, Journal of Measurements in Engineering, 2014, Vol. 2, Issue 2, pp.80-85.
