Development and Testing of Air Foil Bearing System for an Automotive Exhaust Gas Turbocharger

Abstract:

Lubricated bearings are usually used to support and guide the shafts in gas turbines, exhaust gas turbochargers and other turbomachines. The lubricant is also used for cooling the hot parts such as the turbine side of the rotor. The high temperature condition effects a contamination of the compressed air by evaporating the lubricant. In special applications an oil-free operation has to be guaranteed. In other applications an oil lubricated bearing system prevents an immediate engine stop. The use of air foil bearings eliminates the disadvantages of the oil lubricated bearings. An air foil bearing works self-adjusting the necessary gap which depends on relative speed of the rotor and the stator surfaces and on the viscosity of the lubricating fluid. A low rotor speed requires a small bearing gap, whereas the gap must be enlarged for high speed at constant viscosity of the lubricant. An air foil bearing works contact-free in a wide speed range even at small rotation speed depending on design. On an experimental basis an air foil bearing system was developed and tested for a standard automotive exhaust gas turbocharger. The developed bearings need no infrastructure for supplying with lubricant and its cooling and filtering. The air foil bearings was calculated and designed based on the estimated bearing loads. For the manufacturing of the radial wave springs a procedure was developed. A test facility was set up for the experiments. The modified rotor works at the standard rotation speed of 80000 rpm. The bearings support and guide the shaft contact-free (without wear) in a range of a few thousands of revolutions per minute up to the standard rotation speed.

• Periodical: Applied Mechanics and Materials (Volume 831)
• Pages: 71-80
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.831.71
• Online since: April 2016
• Authors: Uwe Borchert*, Antonio Delgado, Janusz A. Szymczyk
• Keywords: Air Foil Bearing, Exhaust Gas Turbocharger, Gas Turbine

References

[1] Agrawal, G. L.: Foil Air/Gas Bearing Technology An Overview, International Gas Turbine and Aeroengine Congress and Exhibition, June 2nd–5th 1997, Orlando, Publication 97-GT-347.

[2] Bartz, W. J.: Luftlagerungen – Grundlagen und Anwendungen, 2. Auflage, Ehningen, Expert Verlag, 1993, ISBN: 3-81690992-2.

[3] Roloff/Matek: Maschinenelemente – Normung, Berechnung, Gestaltung, 18. Auflage, Wiesbaden, Vieweg Verlag, 2007, ISBN: 978-3-8348-0262-0.

DOI: 10.1007/978-3-658-34160-2_25

[4] Wiebelt, A.: Zylinderrollenlager mit aerostatischem Käfig zur Lagerung schnelldrehender und thermisch hochbelasteter Rotoren, Dissertation, Karlsruhe, (2002).

[5] Lang, O. R. & Steinhilper W.: Gleitlager, Band 31, Berlin, Heidelberg, New York, Springer Verlag, 1978, ISBN: 3-540-08678-1.

[6] DellaCorte, C. et al.: Design, Fabrication and Performance of Open Source Generation I and II Compliant Hydrodynamic Gas Foil Bearings, Technical Publication, NASA/TM 2007-214691, (2007).

DOI: 10.1115/ijtc2007-44085

[7] DellaCorte, C. & Valco, M. J.: Load Capacity Estimation of Foil Air Bearings for Oil-Free Turbomachinery Applications, Technical Publication, NASA/TM 2000-209782, (2000).

DOI: 10.1080/10402000008982410

[8] Dykas, B. et al.: Design, Fabrication and Performance of Foil Gas Thrust Bearings for Microturbomachinery Applications, Technical Publication, NASA/TM 2008-215062, (2008).

DOI: 10.1115/1.2966418

[9] Kousuke, I. et al.: Development of Micromachine Gas Turbines at Tohoku University, International Conference Micro Gas Turbines, March 14th–16th 2005, Rhode Saint Genèse, Conference Proceedings.

[10] Borchert, U., Delgado, A. & Szymczyk, J. A.: Air Bearing Guided High Temperature Flow Control, in Developments in Mechanical Engineering, hrsg. von Janusz T. Cieśliński, Vol. 4, Gdańsk, 2010, p.29–39, ISBN: 978-83-7348-301-9.

[11] Borchert, U., Seidel, J., Iwan, J. & Delgado, A.: Gasturbinenstufenprüfstand mit mechanischer Leistungsmessung zur Optimierung des Turbinenaustritts, in 3rd International Conference Low Temperature and Waste Heat Use in Communal and Industrial Energy Supply Systems – Theory and Practice, hrsg. von Sławomir Smoleń, 25–26 Oct 2012, Bremen, 2012, S. 9–16.
