Groove Overhang Impact on the Result of Surface Roughness on Vertical CNC Milling Process

Abstract:

Computer Numerical Control (CNC) vertical milling is a cutting tool of a work piece by giving CNC G-code program to the milling machine to give the chisel end mill perpendicular to the surface of the work piece. The distance between overhang tool and holder is usually not standard causing the end mill chisel experience minimum and maximum deflection during the cutting process. This research observed the cutting and measuring the surface roughness of the specimen made of BJ37 mild steel. It is of a square shape with a rectangular cross-section cutting parameters of overhang groove, vibration and feeding from the left, the middle, and the right surface. Measurement was done by testing the surface roughness under the conditions of changing the overhang groove, vibration, and small feeding. The observations result in smaller deflection and angle to obtain Ra = 1.64 μm average minimum level of roughness using 25mm overhang with the same feeding of 0.18mm/rev. Ra = 1.64 μm is classified into Group N7 smooth, compared to the use standard 35mm overhang which obtains Ra = 1.88 μm, Group N7 normal. The minimum level of roughness can be obtained due to the smaller feeding.

• Periodical: Applied Mechanics and Materials (Volume 836)
• Pages: 191-196
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.836.191
• Online since: June 2016
• Authors: Agus Sujatmiko, Moh Hartono, R. Edy Purwanto
• Keywords: CNC milling machine, Overhang Groove, Roughness, Vibration

References

[1] Ang L, and Taylor B, 2005. Managing customer profitability using portfolio matrices. Journal of Database Marketing and Customer Strategy Management 12: 298-304.

DOI: 10.1057/palgrave.dbm.3240266

[2] Bright Onesteel Martin - Issue 2, Juli 2003. OSMBTechnical Handbook, Registered Trademarks of OneSteel MBS Pty Limited ABN 76 096 273 979: issue 2.

[3] Budak. E, E.B. Kivanc, 2004. Structural Modeling of End Mills for Form Error and Stability Analysis, International Journal of Machine Tools & Manufacture 44 (2004) 1151–1161.

DOI: 10.1016/j.ijmachtools.2004.04.002

[4] Hayajneh Mohammed T, Montasser S. Tahat b, Joachim Bluhm, (2007).

[5] Jin Kim Su, 2007. Short and safe tool setting by safe space in NC machining. Int J Adv Manuf Techno1 33: 1017–1023.

DOI: 10.1007/s00170-006-0526-2

[6] Lela B, Zivkovi D, D. Baji, 2008. Modeling of Machined Surface Roughness and Optimization Of Cutting Parameters In Face Milling, Metabk 47(4) 331-334.

[7] Nachi, 2009. AG mill Roughing, Super perfomance from a Low Cost End mill, America Inc.

[8] Raksiri Chana, Manukid Parnichkun, 2004. Geometric and force errors compensation in a 3-axis CNC milling machine. International Journal of Machine Tools & Manufacture 44, 1283-1291.

DOI: 10.1016/j.ijmachtools.2004.04.016

[9] Randelovic Sasa, Sasa Zivanovic, 2007. CAD - CAM Data Transfer as a Part Of Product Life Cycle. Series: Mechanical Engineering Vol. 5, No 1, pp.87-96.

[10] Rochim Toufiq, 2007. Buku 1 Klasifikasi Proses, Gaya & Daya Pemesinan, Penerbit ITB.

[11] Saffar R. Jalili, M.R. Razfar, A.H. Salimi And M.M. Khani, 2009. Optimization of Machining Parameter to Minimize Tool Deflection In the End Milling Operation Using Genetic Algrithm. World Applied Sciences Journal 6 (1): 64-69.

DOI: 10.1080/10910340903586483
