Investigation of the Applicability of an iGPS Metrology System to Automate the Assembly in Motion of a Truck Cabin

Abstract:

The assembly of large components is characterized by manual processes and customer-specified products. These are just two of the challenges for the efficient automation of assembly processes. In the field of large component assembly, the goal is to synchronize between the handling system and the moving work piece placed on an unguided transport system. One approach to solve this problem is a direct reference between the product and the assembled work piece. This referencing is done by using a global reference system in which every handling system can be referenced to every work piece throughout the whole production line. This article will show the first results using a global reference to track large components on an unguided conveyor. Moreover, it investigates the question if the metrology system, which was used here, is able to detect even small position deviations on higher frequencies.

• Periodical: Applied Mechanics and Materials (Volume 840)
• Pages: 58-65
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.840.58
• Online since: June 2016
• Authors: Robert H. Schmitt, Walter Kimmelmann, Stefan Quinders, Christoph Storm*, Felix Oberhansberg
• Keywords: Assembly Lines, Automated Assembly, iGPS, Lasertracker

References

[1] Schmitt, R., Schönberg, A., Lamers, C., Demeester, F.: Global referencing systems and their contribution to a versatile production. In: 2011 International Conference on Indoor Positioning and Indoor Navigation (IPIN), Guimarães, Portugal, (2011).

[2] Zäh, M. F., Werner, J.; Tekouo, W.: Montage in Bewegung – die Automatisierung der Fließmontage. In: werkstatttechnik wt-online. Nr. 97, S. 620-624, (2007).

DOI: 10.37544/1436-4980-2007-9-620

[3] Maisano, D. A.; Jamshidi, J.; Maropoulos, P.G.; Mastrogiacomo, L.; Mileham, A.R.; Owen, G. W. : Indoor GPS: system functionality and initial performance evaluation. In: International Journal of Manufacturing Research. Nr. 3, S. 335-349, (2008).

DOI: 10.1504/ijmr.2008.019214

[4] Franceschini F., Galetto M., Maisano D., Mastrogiacomo L., Pralio B.: Distributed Large Scale Dimensional Metrology. Springer Science + Business Media, (2011).

DOI: 10.1007/978-0-85729-543-9

[5] Weckenmann, A.; Gawande, B.: Koordinatenmeßtechnik: Flexible Meßstrategien für Maß, Form und Lage. München [u. a. ], Hanser, (2010).

[6] Hofmann, S.: Numerische Integration von Beschleunigungssignalen. In: Mitteilungen aus dem Institut für Maschinenwesen der Technischen Universität Clausthal, Nr. 38, S. 103-114, (2013).

[7] Tränkler H. Sensortechnik: Handbuch für Praxis und Wissenschaft mit 122 Tabellen. Springer, Berlin, (1998).

DOI: 10.1007/978-3-662-09866-0

[8] Hoffmann, J. : Handbuch der Messtechnik. Hanser Verlag, München, (2011).
