Preliminary Study of Airflow Energy Recovery System for Electric Vehicles: Performance of VAWT with Air Duct

Abstract:

In order to increase the driving range of electric vehicles, a lift-drag hybrid vertical axis wind turbine (VAWT) and an air duct were designed in this paper, which could realize the wind energy recovering. The energy conversion theory of the concentrated wind energy was introduced into the design of air duct. The wind speed would be increased by 30% after concentrated by the air duct which was verified through CFX simulation. The simulation of original vehicle model, wind turbine and air duct were carried out respectively in Ansys Workbench. And after adding the wind energy recovery device, the drag resistance coefficient of the electric vehicle is reduced by about 8.84%. Indoor laboratory tests conducted on a scale-up model show the flow fields inside the air duct and the turbine rotational speeds in different wind conditions. Results show that position 3 is the optimal matching position of wind turbine and air duct where the cut-in speed is about 4.78km/h and the maximum rotational speed of wind turbine is 458rpm.

You might also be interested in these eBooks

Advanced Materials, Structures and Mechanical Engineering II

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 851)

Pages:

538-543

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.851.538

Citation:

Cite this paper

Online since:

August 2016

Authors:

Hao Bin Jiang*, Ao Xue Li, Shi Dian Ma

Keywords:

Aerodynamic Drag, Air Duct, Airflow Energy Recovery, Electric Vehicle, VAWT

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] J. P. Howell. Aerodynamic drag reduction for low carbon vehicles. IMechE's Sustainable Vehicle Technologies 2012 conference. Gaydon, UK, 14-15 November. UK: Woodhead Publishing, (2012).

DOI: 10.1533/9780857094575.4.145

Google Scholar

[2] W. T. Chong, S. C. Poh, A. Fazlizan. Early development of an energy recovery wind turbine generator for exhaust air system. Appl. Energ. 112 (2013) 568-575.

DOI: 10.1016/j.apenergy.2013.01.042

Google Scholar

[3] C. Wang. Research on wind power generation system based on vehicle speed, Master thesis, Beijing Jiaotong University, (2014).

Google Scholar

[4] M. Khaled, A. Alahaer, F. Hachem. Effects of ground vehicle inclination on underhood compartment cooling. Int. J. Automot. Tech. 13(6) (2012) 895-904.

DOI: 10.1007/s12239-012-0090-8

Google Scholar

[5] K. Mansour, P. Meskinkhoda. Computational analysis of flow fields around flanged diffusers. J. Wind Eng. Ind. Aerodyn. 124 (2014) 109-120.

DOI: 10.1016/j.jweia.2013.10.012

Google Scholar

[6] O. Yuji, K. Takashi, S. Akira. Development of a shrouded wind turbine with a flanged diffuser. J. Wind Eng. Ind. Aerodyn. 96 (2008) 524-539.

DOI: 10.1016/j.jweia.2008.01.006

Google Scholar

[7] S. L. Chen, D. Tian, H. S. Xin. Application and operation effect of 200 W concentrated wind energy generator. Trans. Chinese Soc. Agric. Eng. 28(8) (2012) 225-229.

Google Scholar

[8] Q. L. Han, D. Tian, H. K. Wang. Flow field and power output characteristic of the reformative model concentrated wind energy turbine. Trans. Chinese Soc. Agric. Eng. 19(3) (2009) 93-97.

Google Scholar
