Vibration Based Piezoelectric Energy Harvesting

Abstract:

Piezoelectric energy harvesting has applications in aircraft technology, where the piezoelectric patches are attached to the wings of the aircraft to convert the mechanical vibrations into useful electrical energy, which further is used to power the sensors of Aircraft Health Monitoring System, inflight operations like lighting and onboard entertainment. In this article, the performance of vibration based piezoelectric energy harvester (PEH) for a given frequency range is studied. A piezoelectric material that has a maximum piezoelectric coefficient (PZT-G1195) is chosen to increase the effective power output. The output power generated by the harvester due to transverse and longitudinal vibrations are compared. Finally parametric studies are performed on the PEH to analyze the design parameters influencing its performance.

• Periodical: Applied Mechanics and Materials (Volume 852)
• Pages: 846-851
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.852.846
• Online since: September 2016
• Authors: T.S. Shakthivel, Ramesh Gupta Burela*
• Keywords: Composites, Energy Harvesting, Finite Element Method (FEM), Harmonic Analysis, Modal Analysis

References

[1] Hua Yu, Jielin Zhou, Licheng Deng, Zhiyu Wen, 2014, A Vibration-Based MEMS Piezoelectric Energy Harvester and Power Conditioning Circuit, Sensors, 14, 3323-3341.

DOI: 10.3390/s140203323

[2] Alper Erturk, Daniel J. Inman, 2011, Piezoelectric Energy Harvesting, John Wiley & Sons, 1st Ed., Ch. 1, pp.1-12.

[3] Moheimani, Fleming, 2006, Piezoelectric Transducers for Vibration control & Damping, Springer, Ch. 2, pp.9-21.

[4] IEEE standard on piezoelectricity, 1987, ANSI/IEEE Std., 176, pp.1-11.

[5] A. Kumar et al., 2014, Finite element analysis of vibration energy harvesting using lead-free piezoelectric materials: A comparative study, Journal of Asian Ceramic Societies, 2, p.138–143.

DOI: 10.1016/j.jascer.2014.02.001

[6] Ramesh Gupta. B, 2002, Finite element analysis of flexible structures with piezoelectric patch actuators and sensors", Master, s thesis, Department of Civil Engineering, Malnad College of Engineering.

[7] Mercedes C. Reaves, Lucas G. Horta, 2001, Test cases for modeling and validation of structures with piezoelectric actuators, AIAA Journal, 1466.

DOI: 10.2514/6.2001-1466

[8] Y. Amini et al., 2015, Finite element modeling of functionally graded piezoelectric harvesters, Composite Structures, 129, pp.165-176.

DOI: 10.1016/j.compstruct.2015.04.011

[9] Henno Allik, Thomas J.R. Hughes, 1970, Finite element method for piezoelectric vibration, International journal for numerical methods in engineering, 2, pp.151-157.

DOI: 10.1002/nme.1620020202

[10] ANSYS element reference manual & theory manual.
