Creep Characteristic of Sn1.0Ag0.7Cu Lead-Free Solders with Element Addition

Abstract:

In this study, creep properties of lead-free solders based on Sn1.0Ag0.7Cu were investigated. In the solders, germanium, nickel and bismuth were added to improve their mechanical properties. The effect of element addition on their microstructure and creep properties were studied. Creep properties were improved with the element addition. Creep rupture lifetime was the longest for SnAgCuBiNiGe, and that of SnAgCuBi was the second longest. It was made clear that a minimum creep strain rate is useful for lifetime prediction of the solders. An observation of microstructure was performed and coarsening of intermetallics after creep test was identified, resulting in creep rupture. It was found that the addition of bismuth hinders the coarsening of intermetallics and is effective to improve the creep properties of the solders.

You might also be interested in these eBooks

Innovation in Testing and Evaluation of Structural Integrity

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 853)

Pages:

192-196

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.853.192

Citation:

Cite this paper

Online since:

September 2016

Authors:

Fumio Ogawa*, Hiroki Nagao, Takamoto Itoh, Masao Sakane, Mitsuo Yamashita, Hiroaki Hokazono

Keywords:

Creep, Lead-Free Solder, Life Prediction, Microstructure

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] M. Abtew, G. Selvaduray, Lead-free Solders in microelectronics, Mater. Sci. Eng. R, 27 (2000) 95-141.

DOI: 10.1016/s0927-796x(00)00010-3

Google Scholar

[2] J. Glazer, Microstructure and mechanical properties of Pb-free solder alloys for low cost electronic assembly: a review, J. Electron. Mater. 23 (1994) 693-700.

DOI: 10.1007/bf02651361

Google Scholar

[3] J. Shen, Y. C. Liu, H. X. Gao, C. Wei, Y. Q. Yang, Formation of bulk Ag3Sn intermetallic compounds in Sn-Ag lead-free solders in solidification, J. Electron. Mater. 34 (2000) 1591-1597.

DOI: 10.1007/s11664-005-0170-x

Google Scholar

[4] L. Sun, L. Zhang, Properties and microstructure of Sn-Ag-Cu-X lead-free solder joints in electronic packaging, Adv. Mater. Sci. Eng. 639028 (2015).

Google Scholar

[5] N. Hidaka, H. Watanabe, M. Yoshiba, Creep behavior of lead-free Sn-Ag-Cu + Ni-Ge solder alloys, J. Electron. Mater. 38 (2009) 670-677.

DOI: 10.1007/s11664-009-0689-3

Google Scholar

[6] K. Nogita, C. M. Gourlay, T. Nishimura, Cracking and phase stability in reaction layers between Sn-Cu-Ni solders and Cu substrates, JOM, 61 (2009) 45-51.

DOI: 10.1007/s11837-009-0087-6

Google Scholar
