Numerical Simulation and Experimental Investigation of Residual Stress in 06Cr19Ni10 Austenitic Stainless Steel Weld Joint with Effects of Strain-Strengthening

Abstract:

In this paper, Finite Element Modeling (FEM) using Marc software was carried out to investigate the strain-strengthening effect on residual stress in 06Cr19Ni10 austenitic stainless steel weld joint made by MIG welding. The model prediction of residual stress was validated by X-ray Diffraction (XRD) method. It is found that there is a good agreement between the model predictions and the experimental results. The strain-strengthening can significantly improve the distribution of residual welding stress. Specifically in weld zone and the heat-affected zone (HAZ), residual stress decreases with increasing strain-strengthening level.

• Periodical: Applied Mechanics and Materials (Volume 853)
• Pages: 204-208
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.853.204
• Online since: September 2016
• Authors: Lan Qing Tang*, Hui Fang Li, Xiao Xiao Wang, Cai Fu Qian
• Keywords: Austenitic Stainless Steel Weld Joint, Finite Element Model, Residual Stress, Strain-Strengthening, XRD

References

[1] W. Philip, Residual stress and its role in failure, Rep Prog Phys. 70 (2007) 2211–64.

[2] J.Y. Zheng, A.B. Guo, C.J. Miao and L.L. Ma, Cold Stretching Technique for Austenitic Stainless Steel Cryogenic Pressure Vessels, Pressure Vessel. 27(2010) 28-32.

[3] W.C. Jiang, Y. LUO, BY. Wang, W.C. Woo and S.T. Tu, Neutron Diffraction Measurement and Numerical Simulation to Study the Effect of Repair Depth on Residual, J Press Vess-T ASME. 137 (2015) 1-16.

DOI: 10.1115/1.4028515

[4] R. Pamnania, G.K. Sharmab, S. Mahadevanb , T. Jayakumarb, M. Vasudevanb and B.P.C. Raob, Residual stress studies on arc welding joints of naval steel, J Manuf Process. 20(2010) 104-111.

[5] C.H. Lee, K.H. Chang and V.N. Van Do Miao and L. L, Finite element modeling of residual stress relaxation in steel butt welds under cyclic loading, Eng Struc. 103(2015) 63-71.

DOI: 10.1016/j.engstruct.2015.09.001

[6] B.S. Ma, Z.P. Cai, H. Huang, D. Deng, H. Murakawa and J. L. Pan, Investigation of welding residual stress in flash-butt joint of U71Mn rail steel by numerical simulation and experiment, Mater Design. 88 (2015) 1296–1309.

DOI: 10.1016/j.matdes.2015.08.124

[7] M. Peric´, Z. Tonkovic´, A. Rodic´, M. Surjak, I. Boras and S. Švaic´, Numerical analysis and experimental investigation of welding residual stresses and distortions in a T-joint fillet weld, Mater Design. 53(2014) 1052–1063.

DOI: 10.1016/j.matdes.2013.08.011

[8] B. Raj, T. Jaykumar, S. Mahadevan and S. Rai, X-ray diffraction based residual stressmeasurement for assessment of fatigue damage and rejuvenation process forundercarriages of aircraft , J. Nondestr Eval. 28(2009). 157-162.

DOI: 10.1007/s10921-009-0058-4

[9] H. Long, D. Gery And A. Carlier, Prediction of welding distortion in butt joint of thin plates, Mater Design. 30 (2009) 4126-4135.

DOI: 10.1016/j.matdes.2009.05.004
