Free Vibration Analysis of Building Considering Soil Structure Interaction

Abstract:

Modeling and design of foundation are always done without considering the effect of stiffness of the soil. In the conventional non-interaction analysis of building frame settlements are calculated without considering the influence of the structural stiffness. Therefore a modeling and interaction analysis of soil structure interaction will help to find soil stiffness and effects of soil structure interaction on structure. In this paper, soil structure interaction analysis of a symmetric space frame of 2 bays in both x and y direction are assessed with SAP 2000 software. The frame is modeled with different storey resting on raft foundation with fixed base and flexible base. Three types of soil, i.e. hard, medium, and soft soil are used for Soil Structure Interaction (SSI) study. MODAL analysis is carried out to illustrate the effects of soil-raft-structure interaction on the response of structures. The Soil is considered as Winkler model and elastic continuum model. The developed methodology is validated with results available in the literature. The effects of SSI on frequency of modal are studied. The comparison is carried out the frame with different base conditions.The frequency of the building was found to be decreased when SSI was considered.

• Periodical: Applied Mechanics and Materials (Volume 857)
• Pages: 125-130
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.857.125
• Online since: November 2016
• Authors: Thaiba T. Beegam*, Tissa Sebastian
• Keywords: Elastic Continuum, Raft Footing, SAP-2000, Soil Structure Interaction, Winkler Method

References

[1] R.A. Fraser, L.J. Wardle, Numerical analysis of rectangular rafts on layered foundations, Geotech., 26(4), (1976), 613-630.

DOI: 10.1680/geot.1976.26.4.613

[2] W.T. Straughan, Analysis of plates on elastic foundations, Doctoral Thesis, Texas Tech University, Texas, USA, (1990).

[3] W. Y. Shen, Y.K. Chow, K.Y. Yong, A variational approach for analysis of the rectangular raft on elastic half space, Soils and Foundations, 39, (1999), 625-32.

DOI: 10.3208/sandf.39.6_25

[4] J. A. Hemsley, Elastic analysis of raft foundation, Thomas Telford Ltd. Heron Quay, London, (1998).

[5] G. Gazetas, Formulas and charts for impedence of surface and embedded foundations, J. Geotech. Eng., 117(9), (1991).

[6] S.G. Halkude, M.G. Kalyanshetti, S.M. Barelikar, Seismic response of R.C. frame with raft footing considering soil structure interaction, IJCET, 4(3), (2014).

[7] S.G. Halkude, M.G. Kalyanshetti, S.H. Kalyani, Seismic response of R.C. frame with isolated footing considering soil structure interaction, IJERT, 3(1), (2014).

[8] R. Gowda, G. Narayana and B.K. Naranda, Soil flexibility effect on dynamic behaviour asymmetric 3D building frames with strip footing by continuum model, IJERT, (2015).

DOI: 10.17577/ijertv4is060891

[9] J.E. Bowles, Foundation Analysis and Design, Mcgraw hills, New York, (1988).
