Study on Design and Simulation of the Vibration-Reduction of the Damp Structure for the Gearbox

Abstract:

The study on design and simulation of reduce vibration are carried out of the damp structure for the simulative experimental gear case to reduce vibration and noise of the ship gearbox. Multiple projects are designed for the gear case of the damp structure on the basis of the structure characteristic of the gearbox. The finite element analyze computation is carried out of box of gear case under the different project of the damp and the different damp material. The fine damp material and the optimization structure parameters of damp will be ascertained by the analysis of mode and frequency response. The contrastive analysis of vibration and noise is carried out for the box of fore-and-aft treat of damp structure. The analytical result indicates that the vibration and noise of gearbox will be reduced observably when the project of damp is adopted.

• Periodical: Applied Mechanics and Materials (Volume 86)
• Pages: 139-142
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.86.139
• Online since: August 2011
• Authors: Xin Wang, Jin Bo Fu, Xun Min Yin
• Keywords: Box, Damp Vibration-Reduction, Gearbox, Simulation Analysis

References

[1] K. Ding, W. Li, etc.: Practice Technology on Gear and Gear Case Fault Diagnose (Mechanism Industry Publishing Company, Beijing 2005).

[2] S.C. Conlon, S.A. Hambric: Journal of Sound and Vibration Vol. 322( 4-5) (2009), p.901.

[3] R. Fan, G. Meng, J. Yang and C. He: Journal of Sound and Vibration Vol. 319 (1-2) (2009), p.58.
