Strength Analysis of Logix Gear Based on UG

Abstract:

According to the tooth profile theory of Logix gear, this paper discussed a method of parametric modeling based on UG. By this method, 3D model of Logix gear with different parameters can be easily and quickly built, though tooth profile is complicated. And then, it analyzed the bending stress and contact stress of Logix gear. By comparison with the standard involute gear, it showed that Logix gear has higher bending and contact strength. So it is possible this type of gear can be applied in the case of heavy load. So it provided some practical technical guidance on the research of high strength gear and the application of Logix gear.

• Periodical: Applied Mechanics and Materials (Volume 86)
• Pages: 492-495
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.86.492
• Online since: August 2011
• Authors: Jian Hua Wang, Yun Cheng Wang, Fei Xie, Xu Huang
• Keywords: Bending Stress, Contact Stress, Logix Gear, Parametric Modeling

References

[1] T. Komori, Y. Ariga and S. Nagata: Trans of the ASME Vol. 112 (1990), p.430.

[2] X.Y. Feng, A.Q. Wang and X. Ai: Mechanical Transmission Vol. 27 (2003), p.12.

[3] R.G. Li, J.F. Li and X.Y. Feng: Journal of College of Shandong light industry Vol. 17 (2003), p.20.

[4] X.T. Wu: Gear meshing principles (Xi'an Jiaotong University Press, China 2009).
