Anonymous Function Method and its Application in Screw Pump’s Design and Processing

Abstract:

Matlab anonymous function method combining graph with analytical method was proposed in this paper, which was based on the low solving efficiency and low precision of trigonometry transcendental equation for shape line design and sectional profile calculation of screw pump rotor. Parameters of anonymous function can be nested within each other to solve enveloping conditional formula of shape design or intersecting line of sectional profile design for screw pump, the process of which only took several seconds with high precision of 10E-08mm. What’s more, this method could also be adopted in the forming tool design with spiral cross section, which could largely improve design efficiency and calculation precision.

• Periodical: Applied Mechanics and Materials (Volume 86)
• Pages: 500-503
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.86.500
• Online since: August 2011
• Authors: Yuan Xun Zhang, Qian Tang, Xian Zhi Ye
• Keywords: Anonymous Function, MATLAB, Section, Shape Line, Transcendental Equation

References

[1] S.H. Tone, D. C. H. Yang: ASME Journal of Mechanical Design Vol. 127 (2005), p.287.

[2] L. Wang, H.Q. Wang: China Plastics Industry Vol. 31(2003), p.27.

[3] C.F. Hsieh, Y.W. Hwang, Z.H. Fong: Journal of Mechanism and Machine Theory Vol. 43(2008), p.812.

[4] Westenbroek, Annita P H: Paper Technology Vol. 4(2004), p.37.

[5] Y. W. Hwang, C. F. Hsieh: Journal of Mechanical Engineering Science Vol. 9 (2006), p.1375.

[6] J.N. Xu, Y.L. Feng, W.T. Qu: Journal of Oil Field Equipment Vol. 35(2006), p.5.

[7] F. Cao, X. Peng, Z. Xing: Journal of Fluid Machinery Vol. 29(2001), p.15.

[8] H.C. Liu, S.H. Tone, D.C. Yang: ASME Journal of Mechanical Design Vol. 4 (2000), p.536.

[9] N. Stosic: International Journal of Machine Tools & Manufacture Vol. 46(2006), p. (1961).
