Development of High Power LED Driver Using LNK418EG

Abstract:

Currently, the use of Light Emitting Diodes (LED) bulbs has been intensively increasing since LED possess various qualifications of high efficiency in light production, not radiating heat, no toxic substance, lifespan longer than other bulbs. However, when the circuit of LED Driver is connected directly to high power LED with an AC source, it causes high losses of energy and the occurrence of the non-sinusoidal waveforms thus causing the harmonic series in the power supply system. In the research, a circuit for driving high power LED at high power of 30 watts was created by using a Fly-Back converter converting AC into DC current. At the same time, IC LinkSwitch-PH model LNK418EG was applied to act as a factor correction for electric power and control the constant output currents and electromotive force. After the input AC current at 180-240 volts was applied on the experimental circuit, the input current which has the waveform close to a sine shape resulted in the low distortion of the input current but provided the constant output current and electromotive force. LED’s high luminance could be detected at 300 luxs at a distance of one meter and its performance was 90 percentages.

You might also be interested in these eBooks

Innovative Technology and Sustainable Engineering

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 866)

Pages:

345-349

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.866.345

Citation:

Cite this paper

Online since:

June 2017

Authors:

Nitipat Eawsakul*, Chalermpol Reaungepattanawiwat

Keywords:

Driver, Flyback Converter, High Power LED

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] C.A. Cheng, H.L. Cheng, F.L. Yang, C.W. Ku, Single-stage driver for supplying high-power light-emitting-diodes with universal utility-line input voltages, IET Power Electronics. 5 (2012) 1614-1623.

DOI: 10.1049/iet-pel.2011.0478

Google Scholar

[2] M.I.M. Rashid, S. Ab. Ghani, M.F.S. Mustahim, Development of High Power LED Driver Using LTSpice Software, Power Engineering and Optimization Conference. 2013 IEEE 7th International (2013) 92-97.

DOI: 10.1109/peoco.2013.6564522

Google Scholar

[3] Y. Guo, S. Li, A.T.L. Lee, S.C. Tan, C.K. Lee, S.Y.R. Hui, Single-Stage AC/DC Single-Inductor Multiple-Output LED Drivers, IEEE Transactions on Power Electronics. 31 (2016) 5837-5850.

DOI: 10.1109/tpel.2015.2496247

Google Scholar

[4] Y. Qiu, L. Wang, H. Wang, Y.F. Liu, P.C. Sen, Bipolar Ripple Cancellation Method to Achieve Single-Stage Electrolytic-Capacitor-Less High-Power LED Driver, IEEE Journal of Emerging and Selected Topics in Power Electronics. 3 (2015) 689-713.

DOI: 10.1109/jestpe.2015.2433918

Google Scholar

[5] Y. Yudong, H. Liqun, Design of High power LED driver power supply, Information and Computing Science. 2012 Fifth International Conference (2012) 99-102.

DOI: 10.1109/icic.2012.19

Google Scholar
