Experimental Simulation of Bridges Subjected by Moving Loads

Abstract:

The effect of bridge vibrationinduced bylive loads such as vehicles and pedestrians is an important factor of bridge fatigue damage. It takes much labor and material resource to perform vibration experiments on bridges subjected by real moving loads in field. In order to carry out laboratory experiments on bridges subjected by moving loads, a fixed load with harmonic vibration simulates a moving load on bridge in the beam theory. A simply supported bridge is considered in the present study. The dynamic responses of bridge under different loads are established by the analytic method. Amplitude and frequency of the simulated load are generated on the principle of equal displacements due to both a moving load and a fixed harmonic load impacting on a simply supported beam. Comparisons of numerical results of two types of load on the same beam indicate that the harmonic load can simulate a moving load effectively. It is possible that the field test on bridge can be carried out indoors.

• Periodical: Applied Mechanics and Materials (Volume 873)
• Pages: 208-211
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.873.208
• Online since: November 2017
• Authors: Zhang Jun, Ming Kang Gou, Chuan Liang
• Keywords: Laboratory Experiment, Simply Supported Bridge, Simulated Load, Virtual Reality

References

[1] G. Michaltsos, D. Sophianopoulos, A. N. Kounadis, The effect of a moving mass and other parameters on the dynamic response of a simply supported beam, J. Sound Vibr. 191(3) (1996) 357-362.

DOI: 10.1006/jsvi.1996.0127

[2] L. Fryba, Vibration of solids and structures under moving loads, Noordhoff International, Groningen, (1972).

[3] G. H. Li, The vibration and stability of bridge structures, Chinese Railway Publishing House, Beijing, (1992).

[4] R. W. Clough, J. Penzien, Dynamics of structures. McGraw-Hill Inc., (1975).
