A Simulation Study on Improving Formability of SUS304 Sheet Metal Deep Drawing Process

Abstract:

In the traditional mold manufacturing process, manual methods are mostly used to design, fabricate and then perform forming test to find out the reasonable processing mode for the product. Thanks to the development of technology, the forming design can be greatly reduced by using commercial software. This study uses a combination of ABAQUS software and TAGUCHI algorithms to calculate and design products. By using simulation tool, the fracture, safety, wrinkles as well as stress and strain on the surface of the product can be easily predicted after forming process. So that, the forming process were firstly simulated and executed on the software to find out important parameters. The variance analysis (ANOVA) was then performed to assess the effect of each parameter. Finally, the optimum solution for the product was selected based on ranking levels of each parameter.

• Periodical: Applied Mechanics and Materials (Volume 889)
• Pages: 197-202
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.889.197
• Online since: March 2019
• Authors: Nguyen Duc Toan*, Duc Thuyen Vu
• Keywords: ANOVA, Finite Element Method (FEM), SUS304 Stainless Steel, Taguchi

References

[1] GM Goodwin, Application of strain analysis to sheet metal forming problems in the press shop, (1968).

[2] Nguyen, D.T. and Kim, Y.S. Combination of isotropic and kinematic hardening to predict fracture and improve press formability of a door hinge,, Proc. Inst. Mech. Eng., Part B: J. Eng. Manuf., Vol.224, pp.435-445, (2010).

DOI: 10.1243/09544054jem1687

[3] Nguyen, D.T., Park, J.G., Lee, H.J. and Kim, Y.S. Finite element method study of incremental sheet forming for complex shape and its improvement,, Proc. Inst. Mech. Eng., Part B: J. Eng. Manuf., Vol.224, pp.913-924, (2010).

DOI: 10.1243/09544054jem1825

[4] Nguyen, D.T., Kim, Y.S and Jung, D.W. Finite element method study to predict spring-back in roll-bending of pre-coated material and select bending parameters" )., Int. J. Precis. Eng. Manuf., Vol. 13(8), pp.1425-1432, (2012).

DOI: 10.1007/s12541-012-0187-z

[5] Taguchi, G. On-line Quality Control during Production. Japan Standard Association, Tokyo, (1981).

[6] Hecker, SS. Simple technique for determining forming limit curves,. Sheet Metal Industr. Vol. 52, p.671–676, (1975).

[7] S. P. Keeler, Forming Limit Criteria — Sheets, Advances in Deformation Processing, 1978, pp.127-157.

DOI: 10.1007/978-1-4613-4024-9_4

[8] SIMULIA, Abaqus 6.13-1, Analysis User's Manual, Vol. 1, (2011).
