Dynamic Simulation of Underground Excavation and Support Based on Three-Dimensional Finite Element Method

Abstract:

It is quite important and complicated to simulate sequential excavation and support process effectively and reasonably in underground engineering. To solve this problem, firstly a numerical equation to calculate excavation release loads is proposed concerned with the numerical format of finite element method. And then, an approach to dynamically simulate the excavation and support construction sequentially is put forward, in adopt of the load distribution. On the basis of the distribution of plastic coefficient of the surrounding rock, the load distribution coefficient is identified. The sequential excavation problem is transformed to simple load operation through the FEM calculation. Finally, a case study is further illustrated and it is proved that the approaches could reasonably simulate the dynamic excavation and support process and the effect of support.

• Periodical: Applied Mechanics and Materials (Volumes 90-93)
• Pages: 197-200
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.90-93.197
• Online since: September 2011
• Authors: Hui Bo Liu, Ming Xiao, Jun Tao Chen
• Keywords: Dynamic Simulation, Excavation and Support, Finite Element Model (FEM), Rock Mechanic

References

[1] L. Jing. Int J Rock Mech Min Sci, Vol.40(2003), p.283~353.

[2] S. Choi, H. Shin. Int J Rock Mech Min Sci, Vol.41(2004), pp.876-881

[3] M. Xiao, C. Ye, Z. H. Fu. Rock Soil Mech, Vol.28(12)(2007), pp.2501-2505. in Chinese.

[4] V. Hajiabdolmajid, P. Kaiser. Tunnelling and Underground Space Technology, Vol.18(1) (2003), pp.35-48.

[5] T. Maejima, H. Morioka and T. Mori. Tunnelling and Underground Space Technology, Vol.18(2-3)(2003), pp.223-232

[6] Bofang Zhu. The finite element method theory and applications (3rd edition), 2009. in Chinese.
