Sloshing and Stress Analysis of an API 620 Tank under Seismic Excitation Based on SNI 03-1726-2019: Numerical Evaluation of Code Provisions

Abstract:

Several studies have investigated sloshing due to seismic excitation, mainly focusing on baffle effects and cyclic or recorded seismic loads. This study analyzes the seismic impact on an 80,000 m³ fuel storage tank in Tuban, East Java. Seismic events can cause fluid sloshing, increasing pressure on the tank walls and roof. Utilizing general-purpose finite element software, the sloshing phenomena are simulated using input dynamic loading in spectral response acceleration representing typical seismic loading per the Indonesian standard (SNI). It compares the traditional API 620 method with numerical simulations, revealing a 38% difference in sloshing height and a 40% difference in dynamic hoop stress. The numerical simulations predict a lower sloshing height due to unaccounted warm gas pressure, while the traditional method estimates less dynamic hoop stress. Although the API 620 method is more straightforward for design, numerical simulations provide a deeper understanding of sloshing pressure effects, enhancing asset integrity assessment.

• Periodical: Applied Mechanics and Materials (Volume 932)
• Pages: 9-22
• DOI: https://doi.org/10.4028/p-nFm7Jm
• Online since: February 2026
• Authors: Aldarifa Putri Nabilah*, Rachman Setiawan, Ade Nadjuri
• Keywords: API 620, Fluid Sloshing, Numerical Simulation, SNI 03-1726-2019, Storage Tanks

References

[1] Boyun. Guo and Ali. Ghalambor, Natural gas engineering handbook. Gulf Pub. Co., 2005.

[2] R. Amorin, E. Broni-Bediako, D. Worlanyo, and S. A. Konadu, "The Use of Liquefied Petroleum Gas (LPG) as a Fuel for Commercial Vehicles in Ghana: A Case Study at Tema Community 1," Current Journal of Applied Science and Technology, vol. 29, no. 2, p.1–8, Sep. 2018.

DOI: 10.9734/cjast/2018/41531

[3] S. , P. R. L. , S. S. , & A. A. Sembiring, "Pemanfaatan Gas Alam Sebagai LPG_Sembiring," Jurnal Teknik ITS, vol. 8, no. 2, 2019.

DOI: 10.12962/j23373539.v8i2.47079

[4] F. Synák, K. Čulík, V. Rievaj, and J. Gaňa, "Liquefied Petroleum Gas as an Alternative Fuel," in Transportation Research Procedia, Elsevier B.V., 2019, p.527–534.

DOI: 10.1016/j.trpro.2019.07.076

[5] Badan Pusat Statistik, "5. NERACA ENERGI INDONESIA 2015-2019," Badan Pusat Statistik, vol. 1, no. 1, p.1–80, 2020.

DOI: 10.21002/jepi.2022.13

[6] M. Jäger, "Fuel Tank Sloshing Simulation Using the Finite Volume Method," Graz, Austria, 2019.

[7] M. Zain, R. Kangda, M. Z. Kangda, S. S. Sawant, and O. R. Jaiswa, "Sloshing in Liquid Storage Tanks With Internal Obstructions," in Structural Engineering Convention (SEC-2016), 2016.

DOI: 10.1007/978-981-13-0365-4_1

[8] J. R. Cho, H. W. Lee, and S. Y. Ha, "Finite Element Analysis of Resonant Sloshing Response in 2-D Baffled Tank," J Sound Vib, vol. 288, no. 4–5, p.829–845, Dec. 2005.

DOI: 10.1016/j.jsv.2005.01.019

[9] H. Akyildiz and N. Erdem Ünal, "Sloshing in a Three-Dimensional Rectangular Tank: Numerical Simulation and Experimental Validation," Ocean Engineering, vol. 33, no. 16, p.2135–2149, Nov. 2006.

DOI: 10.1016/j.oceaneng.2005.11.001

[10] S. M. Hasheminejad and M. Aghabeigi, "Liquid Sloshing in Half-Full Horizontal Elliptical Tanks," J Sound Vib, vol. 324, no. 1–2, p.332–349, Jul. 2009.

DOI: 10.1016/j.jsv.2009.01.040

[11] W. Wang, Z. Guo, Y. Peng, and Q. Zhang, "A Numerical Study of the Effects of the T-Shaped Baffles on Liquid Sloshing in Horizontal Elliptical Tanks," Ocean Engineering, vol. 111, p.543–568, Jan. 2016.

DOI: 10.1016/j.oceaneng.2015.11.020

[12] M. Hosseini, M. A. Goudarzi, and A. Soroor, "Reduction of Seismic Sloshing in Floating Roof Liquid Storage Tanks by Using a Suspended Annular Baffle (SAB)," J Fluids Struct, vol. 71, p.40–55, May 2017.

DOI: 10.1016/j.jfluidstructs.2017.02.008

[13] L. Battaglia, M. Cruchaga, M. Storti, J. D'Elía, J. Núñez Aedo, and R. Reinoso, "Numerical Modelling of 3D Sloshing Experiments in Rectangular Tanks," Appl Math Model, vol. 59, p.357–378, Jul. 2018.

DOI: 10.1016/j.apm.2018.01.033

[14] D. Liu, P. Lin, M. A. Xue, L. Cheng, and J. Lian, "Numerical Simulation of Two-Layered Liquid Sloshing in Tanks Under Horizontal Excitations," Ocean Engineering, vol. 224, Mar. 2021.

DOI: 10.1016/j.oceaneng.2021.108768

[15] W. H. Tsao and Y. L. Huang, "Sloshing Force in a Rectangular Tank With Porous Media," Results in Engineering, vol. 11, Sep. 2021.

DOI: 10.1016/j.rineng.2021.100250

[16] M. A. Xue, Z. Jiang, P. Lin, J. Zheng, X. Yuan, and L. Qian, "Sloshing Dynamics in Cylindrical Tank With Porous Layer Under Harmonic and Seismic Excitations," Ocean Engineering, vol. 235, Sep. 2021.

DOI: 10.1016/j.oceaneng.2021.109373

[17] American Petroleum Institute, "Welded Tanks for Oil Storage," Washington DC, 2019.

[18] T. N. Salem, H. M. Maaly, and A. M. Abdelbaset, "Dynamic Analysis of Aboveground Steel Storage Tanks Over Stiff Soil," Soil Mechanics and Foundation Engineering, vol. 59, no. 1, p.44–50, Mar. 2022.

DOI: 10.1007/s11204-022-09782-y

[19] M. Djermane, D. Zaoui, B. Labbaci, and F. Hammadi, "Dynamic Buckling of Steel Tanks Under Seismic Excitation: Numerical Evaluation of Code Provisions," Eng Struct, vol. 70, p.181–196, Jul. 2014.

DOI: 10.1016/j.engstruct.2014.03.037
