Study on Damage Identification for Reinforced Concrete Structures Based on Wavelet Transform

Abstract:

Reinforced concrete structures are prone to damage during their service lifetime caused by factors such as the effect of overload, ground motions, and other actions. Undetected damage may lead to structural failures. Early detection of damage and timely repairs can prevent catastrophic failure and ensure regular service of structures. As a result, a so-called delimitation wavelet-transform search method, based on the characteristic of multi-resolution of wavelet transform, is presented in this paper for on-line damage identification of reinforced concrete structures. One possible advantage of this method is that the damage temporal and spatial location can be detected rapidly and efficiently. Further research is carried out with numerical simulation of a structure test model to study the storied damage detection and localization of reinforced concrete frame structures under seismic actions. The analyzing result is compared with that observed in a simulated earthquake vibration stand test. Good agreement is obtained and it verifies the effectiveness and validity of the method proposed in this paper.

• Periodical: Applied Mechanics and Materials (Volumes 94-96)
• Pages: 1505-1510
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.94-96.1505
• Online since: September 2011
• Authors: Xiao Yu Miao, She Liang Wang, Yu Jiang Fan
• Keywords: Damage Identification, Multi-Resolution, Numerical Simulation, Shaking Table Test, Wavelet Transform (WT)

References

[1] Cui Fei, Yuan Wan-cheng. Spline Function Method for Damage Detection of Structures [J]. Journal of Tongji University, 2002，30（8）:907-910

[2] Zhou Xian-yan, Shen Pusheng. Study of Damage Assessment of Concrete Structures by Strain Model Method [J]. Journal of Hunan University, 1997，24（5）:69-74

[3] Tang He-sheng, Xue Song-tao. Influence on Structural Damage Identification with Wavelet Band Changes [J]. Journal of Tongji University, 2003，31（8）:883-887

[4] W.J. Staszewski. Structural and mechanical damage detection using wavelet [J]. The Shock and Vibration Digest, 1998,30(6):457-472

DOI: 10.1177/058310249803000602

[5] Z.Hou, M.Noori, R.St.Amand. Wavelet-based approach for structural damage detection [J]. Journal of Engineering Mechanics, 2000,126(7):677-683

DOI: 10.1061/(asce)0733-9399(2000)126:7(677)

[6] Zhang Li-xin, Li Zheng, Su Xian-yue. Application of Wavelet Transform Analysis in Defects-Detection [J]. Journal of Experimental Mechanics, 2002，17（1）:17-22

[7] Tang He-sheng, Xue Song-tao. Analysis of Online Structural Damage Detection Based on Wavelet Transform [J]. Acta Mechanica Solida Sinica, 2004，25（1）:47-52

[8] Li Hong-qua, Dong Liang. Identification of Structural Damage and Test Study Based on Wavelet Transform [J].China Civil Engineering Journal, 2003，36（5）:52-57

[9] Ran Qi-wen, Tan Li-ying. Wavelet Analysis and Fractional Fourier Transform and their usage [M]. Beijing: National Defence Industry Press, (2002)

[10] Hu Chang-hua, Li Guo-hua. Analysis and Design Based on MATLAB-Wavelet Analysis [M]. Xi'an: Xidian University Publishing House, (2004)

[11] Liu Da-hai. Seismic Design of Super High-Rise Building [M]. Beijing: China Architecture & Building Press, (1993)

[12] Hu Lv-xian. Earthquake engineering [M].Beijing: seismic press,(1988)
