Dynamic Elasto-Plastic Analysis on the Steel Spatial Arch Truss with 90m Span under Earthquake

Abstract:

In this paper, the elasto-plastic dynamic analysis on the steel spatial arch truss with 90m span and 0.4 rise-span ratio is carried out under earthquake EL-Centro wave with SAP2000. In the analyses, the geometric and material nonlinear effects are considered at the same time based on the plastic-hinge theory. Under the action of EL wave with the peak increasing gradually, its elasto-plastic dynamic responses have been obtained. All the results displays its failure mode under the earthquake action is elasto-plastic dynamic buckling; that its critical peak acceleration of EL earthquake wave when applied in X direction is 381gal, and is 583gal when applied in Z direction; The ratio of its maximal node horizontal and its structural height is 1/290, and its displacement ductility coefficient is 1.43 and the ratio of its bars with plastic hinge appearing when buckling is 3.00% when EL-Centro waves applied on structure in X direction; The ratio of its maximal node vertical and its structural span is 1/567, and its displacement ductility coefficient is 1.48 and the ratio of its bars with plastic hinge appearing when buckling is 2.50% when EL-Centro waves applied in Z direction.

• Periodical: Applied Mechanics and Materials (Volumes 94-96)
• Pages: 736-739
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.94-96.736
• Online since: September 2011
• Authors: Hai Wang Li, Wei Ping Sun, Jing Liu
• Keywords: Dynamic Elasto-Plastic, Plastic Hinge, Steel Arch Truss, Time History Analysis

References

[1] Haiwang LI, Xuefeng SHU, Fei ZHI. A new function for large-span civil buildings Proceedings of the International Association for Shell and Spatial Structures (IASS) Symposium 2009, 28 September – 2 October 2009, Universidad Politecnica de Valencia, Spain:358-359.

[2] Civil King Software Technology Co., Ltd. China institute of Building Standard Design & Research. Usage guide to Structure Analysis Program 2000 Chinese edition [CP]. China Communications Press. (In Chinese)

[3] GB50011-2001(2008 edition) Code for seismic design of buildings[S]. Beijing: China architecture & building press, 2008. (In Chinese)

[4] FEM 356 The Seismic Rehabilitation of Buildings[S]. Federal Emergency Management Agency,2000.

[5] Shizhao Shen, Xin Chen．Dynamic stability of grid structure[M]．Beijing, Science Press, 1999. (In Chinese)

[6] Haiwang LI and Jianxian LI and Fei ZHI and Fu MA and Dongqi QIN. A parameter study on dynamic buckling of spatial arch trusses under seismic action. Proceedings of the 6th International Conference on Computation of Shell and Spatial Structures IASS-IACM 2008: "Spanning Nano to Mega" 28-31 May 2008, Cornell University, Ithaca, NY, USA.

DOI: 10.1016/j.engstruct.2007.07.002
