Thermography Diagnostics of Photovoltaic Panels

Abstract:

The technologies based on photovoltaic effect, which achieve their fulfilment from small applications to some big power stations that can be in size of few square kilometers, still come to the fore more. The growth of the interest and installations of these technologies brought also amount of technical, legislative or financial problems and also in issues of safety of its operation, of its service, of intervention of rescue squad and last but not least of recycling. Solar thermography is the use of an infrared camera to inspect photovoltaic solar systems for problems that can cause; damage to the cells, loss of efficiency, and fire hazards. In this work were observed temperature distributions for solar panel using digitized thermal imagers and the detected problems with the overheated connections at the junction box from the front of the panel and problems with a defective cell. Also were detected problems of photovoltaic panel with the overheated place caused by dirt on the panel.

• Periodical: Advanced Materials Research (Volume 1001)
• Pages: 388-392
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1001.388
• Online since: August 2014
• Authors: Jozef Fiala*, Marcel Kuracina, Lenka Blinová, Maroš Soldán
• Keywords: Photovoltaic, Thermal Imagers, Thermography

References

[1] FLUKE Corporation: Using thermal imagers in photovoltaic plant maintenance, Application Note, Netherlands (2010).

[2] J. Fiala et al., (2013): Study of Hydrogen Production Using Photovoltaic, Applied Mechanics and Materials, Vol. 291-294, p.593.

[3] J. A. Tsanakas , D. Chrysostomou , P. N. Botsaris & A. Gasteratos (2013).

[4] Thermal imaging guidebook for building and renewable energy applications, FLIR Systems AB (2011), Information on: http: /www. flir. com/uploadedFiles/Thermography/MMC/Brochures/ T820325/T820325_APAC. pdf.

[5] Spagnolo, G.S. et al., (2012) A review of IR thermography applied to PV systems. 11th International Conference on Environment and Electrical Engineering, EEEIC 2012 - Conference Proceedings. Venice; Italy. ISBN: 978-145771828-1.

DOI: 10.1109/eeeic.2012.6221500

[6] Avdelidis, N. P., A thermographic survey for evaluating in situ the performance of photovoltaic panels, Proc. SPIE 8013, Thermosense: Thermal Infrared Applications XXXIII, 80130K (May 10, 2011); doi: 10. 1117/12. 883367.

DOI: 10.1117/12.883367

[7] Nuri Gokmen et al., Simple diagnostic approach for determining of faulted PV modules in string based PV arrays, Solar Energy, Volume 86, Issue 11, November 2012, Pages 3364-3377, ISSN 0038-092X, http: /dx. doi. org/10. 1016/j. solener. 2012. 09. 007.

DOI: 10.1016/j.solener.2012.09.007
