The Influence of Ferrite Materials to NFC Antenna

Abstract:

The electromagnetic (EM) shielding sheets,ferrite materials, ofen sandwiched between NFC (Near Field Communication) tag and metal to increase its detection distance. However, the addition of this ferrite materials could affect the NFC antenna other performance at the same tine, especially the impedance and working frequency. In this paper and investigation, we proved that ferrite materials have an abvious influence on NFC antenna impedance and working frequency via HFSS and ADS simulation. When the real part of permeability of the EM shielding sheet changed from 90 to 150, the working frequency drifited from designed working frequency 13.56 MHz to 12.87 MHz as the rapid increasing of antenna port impedance. Using Magneto-Dynamic Analysis,the corresponding explanation is given.

• Periodical: Advanced Materials Research (Volumes 1006-1007)
• Pages: 994-999
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1006-1007.994
• Online since: August 2014
• Authors: Qing Zhao, Di Fei Liang, Dong Yue Li
• Keywords: Ferrite Sheet, Frequency Drift, Impedance, NFC Antenna

References

[1] NFC-Forum, Available: http: /www. nfc-forum. org.

[2] Kerem OK, Vedat COSKUN, et al. Current Benefits and Future Directions of NFC Services. 2010 International Conference on Education and Management Technology(ICEMT 2010).

DOI: 10.1109/icemt.2010.5657642

[3] Benyo B, Vilmos A, Kovacs K, et al. NFC applications and business model of the ecosystem[C]/Mobile and Wireless Communications Summit, 2007. 16th IST. IEEE, 2007: 1-5.

DOI: 10.1109/istmwc.2007.4299324

[4] Dominikus S, Aigner M. mCoupons: An application for near field communication (NFC)[C]/Advanced Information Networking and Applications Workshops, 2007, AINAW'07. 21st International Conference on. IEEE, 2007, 2: 421-428.

DOI: 10.1109/ainaw.2007.230

[5] Siira E, Tormanen V. The impact of NFC on multimodal social media application[C]/Near Field Communication (NFC), 2010 Second International Workshop on. IEEE, 2010: 51-56.

DOI: 10.1109/nfc.2010.16

[6] Sodor B, Fordos G, Doktor T, et al. Building a contactless university examination system using nfc[C]/Intelligent Engineering Systems (INES), 2011 15th IEEE International Conference on. IEEE, 2011: 57-61.

DOI: 10.1109/ines.2011.5954719

[7] Shuoqing Yan, et al. Preparation and characterization of ferrite with Co substituted NiCuZn sheets application for 13. 56MHz radio frequency identification communication. JOURNAL OF APPLIED PHYSICS 115, 17A529 (2014).

DOI: 10.1063/1.4868324

[8] EMV Contactless Specifications for Payment Systems. page13.

[9] M. Bensetti et al., A hybrid finite-element method for the modeling of microcoils, IEEE Trans. Magn., 41(5): 1868-1871, (2005).

DOI: 10.1109/tmag.2005.846284

[10] Roland, M., Witschnig, H., Merlin, E., & Saminger, C. (2008).
