Optimization of Pass Design of Bidirectional Thermal-Insulation Bricks

Abstract:

The thermal performance of perforated brick is affected by various factors, thermal conductivity, the holes rates, the pass design and etc. included. In order to analyze the impact of the pass design on the thermal performance of bidirectional thermal insulation bricks, the two-dimensional finite element model was developed using ANSYS. The simulated result shows that existence of vertical holes can enhance the thermal resistance in the longer dimension of the perforated brick. Under the condition of the same holes rates, narrowing the width of the vertical holes helps to improve the thermal resistance in the shorter dimension of the perforated brick. The function of these blocks are extremely influenced by the distribution of the vertical holes, the concentrated better than the both-sided when it comes to advancing the whole function.

• Periodical: Advanced Materials Research (Volumes 1008-1009)
• Pages: 1348-1351
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1008-1009.1348
• Online since: August 2014
• Authors: Sha Sha Dong*, Xiao Ping Feng
• Keywords: Bidirectional Thermal Insulation, Pass Design, Thermal Resistance

References

[1] TIAN Bin-shou, DUAN Zhao-rui, FENG Qi-biao, YANG Shu-xin. Test method of heat resistance of concrete hollow block [J]. Construction Quality, 2009, 10: 62-64.

[2] Yan-hua Sun, Wei-min Sun. Theory analysis on thermal insulation coefficient of hollow concrete block wall [J]. Insulation materials and energy-saving building, 2002, 5: 27-29.

[3] PENG Han-xiang YUAN Jian-wei XU Sheng. Study on the numerical simulation of the temperature field of the energy saving perforated concrete brick wall[J]. Shan Xi Structure, 2008, 34: 23-24.

[4] CHEN Li-qun, YANG Wei-jun. Calculated method for thermal parameters of multi-hole concrete block[J]. Brick & Tile World, 2010, 3: 21-23.
