Electromechanical Coupling Study on the Pull-in Parameters of Electrostatic Cantilever Microbeam

Abstract:

In this paper, the coupling electromechanical model is proposed for a cantilever microbeam in microelectromechanical system (MEMS). Based on mechanics of plate and theories of electrostatic field, the coupling electromechanical behavior of the cantilever microbeam is investigated. The pull-in voltage is accomplished using the increment-iterative method. The effectiveness of the proposed method is verified by comparing numerical results with that in the literature. The numerical results show that the pull-in voltage decreases with the improvement of the ratio of the width of micro beam to the initial gap between the electrodes.

• Periodical: Advanced Materials Research (Volumes 102-104)
• Pages: 36-40
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.102-104.36
• Online since: March 2010
• Authors: Ye Tao, Sheng Wen
• Keywords: Cantilever Microbeam, Electromechanical Coupling, Pull-In Voltage

References

[1] J.M. Huang, K.M. Liew and C.H. Wong: Sensors Actuators, Vol. 93 (2001), pp.273-285.

[2] W.S. N Trimmer and K.J. Gabriel: Sensors Actuators, Vol. 11 (1987), pp.189-206.

[3] J. Fricke and E. Obermeier: Sensors and Actuators, Vol. 54 (1996), pp.651-655.

[4] Y. Sun, B.J. Nelson and D.P. Potasek: J. Micromech. Microeng, Vol. 12 (2002), pp.832-840.

[5] A. Selvakumar and K. Najafi: J. Micromech. Microeng, Vol. 7 (1998), pp.192-200.

[6] V. Rochus, D.J. Rixen and J.C. golinval: Nonlinear Analysis, Vol. 63 (2005), pp.1619-1633.

[7] J.H. Kuang and C.J. Chen: Int. J. Mech. Sci., Vol. 47 (2005), pp.1172-90.

[8] T.H. G Megson: Structural and strss analysis (Arnold, London 1996).
