Analysis of Dispersion Properties of Chirped Long-Period Fiber Grating Based on Two Fiber Analysis Models

Abstract:

In this paper, the difference of core-mode effective refractive indices (RIs) and the long-period fiber grating (LPFG) resonant wavelength in an uniaxial-crystal fiber resulted from two fiber analysis models were demonstrated and analyzed. The two models are two-layered medium model which is normally used for conventional single-mode optical communications fiber and three-layered medium model. Using Transfer Matrix Method (TMM) based on Coupled-Mode Theory (CMT), the different dispersion properties of chirped long-period fiber gratings (CLPFG) calculated by both models were compared. The result shows that the difference of the core-mode effective RIs is significant especially when the cladding radius and cladding mode order are small, which indicates the limitation of the two-layer model, and that reducing the cladding radius and increasing the cladding mode order can improve the CLPFG dispersion compensation capability effectively. This paper provides guidance to the design and accurate analysis of CLPFG based dispersion compensator (DC).

• Periodical: Advanced Materials Research (Volumes 1030-1032)
• Pages: 20-24
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1030-1032.20
• Online since: September 2014
• Authors: Jing Yi Wang, Yu Kun Bai
• Keywords: Chirped Long-Period Fiber Gratings, Dispersion Compensation, Optical Fiber, Transmission Spectrum, Uniaxial-Crystal Fiber Medium Model

References

[1] A.M. Vengsarkar W.A. Reed. Dispersion-commpension single mode fibers : effcient designs for first and second order compensation[J]. Opt. lett. 1993. 18(11), pp.924-926.

DOI: 10.1364/ol.18.000924

[2] S.B. Alleston,P. Harper. 40Gb/s single channel dispersion managed pulse propagation in standard fiber over 509 km[J]. Electron. Lett. 1999. 35(1), pp.57-59.

DOI: 10.1049/el:19990006

[3] Ouellette. Dispersion cancellation using linearly chirped bragg grating filters in opfical wavegnides，Opt. lett. 1987，12(Io), pp.847-849.

DOI: 10.1364/ol.12.000847

[4] S. Thibault,J. Lauzon,J. Cliché. Numerical analysis of the optional length and profile of a linerly chirped fiber Bragg grating for dispersion compensation[J]. Opt. Lett., 1995, 20(6), pp.647-649.

DOI: 10.1364/ol.20.000647

[5] ENNSER K. Optimization of apodized linearly chirped fiber gratings for optical communications [ J ] J Quantum Electronics , 1998 , 34 , pp.770-778.

DOI: 10.1109/3.668763

[6] J．A．R．Willams，I．Bennion, K．Sugden, et al，Fiber dispersion compensation using a chriped in-fiber Bragg grating．Electronics Letters，1994，30(12) , pp.985-987.

[7] K．O．Hill, et al，Chirped in-fiber Bragg grating dispersion compensators：Linearisation of dispersion characteristic and demonstration of dispersion compensation in 100kin，10Gbit/s optical fiber link．Electron．Lett，1994，30(21), pp.1755-1756.

DOI: 10.1049/el:19941214

[8] D.B. Stegall,T. Erdogan. Dispersion control with use of long-period fiber gratings [J]. J. Opt. Soc. Am. A, 2000, 17(2) , pp.302-312.

DOI: 10.1364/josaa.17.000304

[9] Mizrahi V, Sipe J E. Optical properties of photosensitive fiber phase gratings. IEEE Journal of Lightwave Technology. 1993, (11), pp.1513-1517.

DOI: 10.1109/50.249888

[10] Erdogan T. Fiber grating spectra. IEEE Joyrnal of Lightwave Technology. 1997, (15), pp.1277-1294.

DOI: 10.1109/50.618322

[11] Kogelnik H. Theory of optical waveguides. in Guided-Wave Opto-Electronics .T. Tamir, editor New York: Springer-Verlag, (1990).
