Application of the Improved Three-Ratio Method in Chromatographic Analysis of Locomotive Transformer Oil

Abstract:

The chromatographic analysis of gas dissolved in oil can monitor transformer operation state at any time.It will help to find out transformer latent fault.The chromatogram analysis of locomotive transformer oil mainly adopts the improved three-ratio method.This paper introduces the improved three-ratio method and chromatogram analysis steps,through the concrete example,shows that the improved three-ratio method for transformer fault diagnosis result is basically matched with the actual fault reason,and summarizes attentions.
