Analysis of Kinematics and Dynamics of 3UPU/PU Parallel Platform Used in Automatic Wave Compensation

Abstract:

3UPU/PU parallel platform is able to achieve a linear and two rotating motion (3-DOF ) platform,it can used in automatic wave compensation of ship deck equipment. The compensation platform is composed of dynamic and static plate, hydraulic cylinder and driven chain parts; it has strong capacity , simple structure and suitable for most conditions. This paper analysis the motion of the platform using one order and two order influence coefficient, establishes the dynamic model of this platform using the Newton Euler method , obtained the velocity, acceleration and force curve by simulating calculation, lay the foundation for the stable platform’s further dynamic analysis and control.

• Periodical: Advanced Materials Research (Volumes 1049-1050)
• Pages: 1061-1066
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1049-1050.1061
• Online since: October 2014
• Authors: Guang Can Lu*
• Keywords: 3UPU/PU Mechanism, Dynamic, Kinematics, Wave Compensation

References

[1] Stewart, D. A Platform With Six Degree of Freedom. Proceedings of institution of Mechanical Engineers. 1965，180(5): 371-386.

[2] Zhao Tieshi, Chen Jiang. 4-UPU Parallel Manipulator Mechanism and Kinematics [J] , China Mechanical Engineering, 2005, 16 (22): 2034-20381.

[3] Zhang Jianzheng, Liu Wei, GAO Feng. A Newton-Euler Formulation for the Inverse Dynamics of the 6-PSS Parallel Mechanism [J]. 2007, 23 (3): 54-59.

[4] Huang Zhen, Kong ling-fu, Fang Yuefa. Parallel Robot Mechanism and Control Theory [M], Beijing: Mechanical Industry Press, (1997).

[5] Qin Yongyuan. Inertial navigation [M], Beijing: Science Press, May (2006).
