Bracket Electro-Hydraulic Control System Based on PLC Hydraulic Research

Abstract:

Adopt a PLC controller as the core and combined hydraulic supports CAN bus technology to build electro-hydraulic control system, the composition and working principle of hydraulic support electro-hydraulic control system will be described; according to the control system control requirements to achieve a single frame single action moving, single rack sequential linkage, group exercise, shearer position detection and the overall program design, while the stent control system software and hardware design. Verification shows that the system is able to achieve its basic functions. Reference to automate the development of the growing coal mine hydraulic support electro-hydraulic control system.

• Periodical: Advanced Materials Research (Volumes 1049-1050)
• Pages: 1042-1047
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1049-1050.1042
• Online since: October 2014
• Authors: Guo Wei, Li Ji
• Keywords: CAN-Bus, Electro-Hydraulic Control System, Hydraulic Support, PLC

References

[1] Wang Ling, Yang Kun. Research coal hydraulic support electro-hydraulic control system［J］. Coal Mine Machinery, 2013, 34（05）: 191-192.

[2] Wu Xiaojie, Chen Yao, Cui Jianmin, Yu Yueseng. Hydraulic support electro-hydraulic control system design[J]. Coal Science and Technology, 2011, 39（4）: 106-109.

[3] Zhang Xiaoyan. [J Research Status Application mine hydraulic support electro-hydraulic control system]., Chinese high-tech enterprises 2011, 23（7）: 234-235.

[4] Ning Yu. Longwall Face bracket electro-hydraulic control system design. ［J］. Coal Science and Technology, 2009, 37（1）: 1-3.

[5] Wangbao Qin. Tan coal mining hydraulic support electro-hydraulic control system［J］. Coal Technology, 2011, 30（8）: 67-68.

[6] Hou Zhiwei. Design of hydraulic support electro-hydraulic control system［J］. Machine Tool & Hydraulics, 2010, 38（14）: 35-3.
