Micro-Channel Mold Machined by Ultrafine WEDM

Abstract:

In this study, an ultrafine WEDM (wire electrical discharge machining) of micro-channel mold is proposed. It could be divided into two parts, rough machining and finish processing. In rough machining procedure, high machining voltage is adopted to improve machining efficiency. In finish machining procedure, extended and trimmed tool path is adopted to obtain the cusp at the corner, low electrical parameters is adopted to improve surface quality and dimensional precision. By conducting finish machining of 40V, a better surface-quality with Ra of 0.32μm and high aspect ratio of 20:1 was fabricated.

You might also be interested in these eBooks

Modern Technologies in Materials, Mechanics and Intelligent Systems

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 1049-1050)

Pages:

1026-1029

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.1049-1050.1026

Citation:

Cite this paper

Online since:

October 2014

Authors:

Yu Kui Wang*, Xiang Chen, Bo Zhu, Zhen Long Wang

Keywords:

Finish Machining, Micro-Channel Mold, Rough Machining, Ultrafine WEDM

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Wang Xiaodong, Liu Chong, Ma Liqun . Plastic microfluidic chips and its automatic fabrication[ J]. Chinese High Technology Letters, 2004, 14(7): 45-48.

DOI: 10.1109/mhs.2004.1421270

Google Scholar

[2] Zhang Feng, Zhang Hongyi, Zhou Yongliang. Fabrication of PDMS microfluidic chip by wet etching silicon[J]. Mechanical Engineering, 2005, 41(11): 194~198.

DOI: 10.3901/jme.2005.11.194

Google Scholar

[3] Luo Yi, Wang Xiaodong, Liu Chong et al. A new method to fabricate metal hot embossing mould for microfluidic chip[J]. China Mechanical Engineering, 2005, 16(17): 1505~1507.

Google Scholar

[4] Xu Shujie, Duan Yugang, Ding Yucheng et al. New method for rapid fabricating masters of PDMS-based microfluidic devices[J]. Mechanical Engineering, 2007, 43(6): 105~109.

DOI: 10.3901/jme.2007.06.105

Google Scholar

[5] Nihat Tosun, Can Cogun. An Investigation on Wire Wear in WEDM．Journal of Materials Processing Technology．2003，8（9）：273-278.

Google Scholar
